1967 1968 V700 Clutch And Controls
| Position | Part Number | Description |
|---|---|---|
| 10 | 12084100 | CLUTCH SPRING (#12084100) USE 13084100 |
| 11 | 12082900 | PRESSURE PLATE (#12082900) USE 12082901 |
| 12 | 12084400 | CLUTCH PLATE EA SHALLOW SPLINE (#12084400) use 28084460 |
| 13 | 12082300 | CLUTCH INTERMEDIATE PLATE (#12082300) |
| 14 | 12082800 | CUP OR NUT (#12082800) |
| 15 | 12085700 | 12085701 (#12085700) |
| 16 | 12085900 | PUSH ROD SEAL (#12085900) USE 14085900 |
| 17 | 92295704 | BALL (#92295704) |
| 18 | ||
| 19 | 25087000 | BEARING (#25087000) USE 12087000A |
| 20 | 12086100 | 12086101 (#12086100) |
| 21 | 90706150 | O RING (#90706150) |
| 22 | 12090100 | 12090201 (#12090100) |
| 23 | 12090400 | PIN (#12090400) USE 12090401 |
| 24 | 95780271 | PIN (#95780271) |
| 25 | 12093001 | CLUTCH CABLE (#12093001) USE 12093045 |
| 25 | 95100130 | WASHER (#95100130) |
| 25 | 95500222 | SPLIT PIN (#95500222) |
| 26 | 12093000 | CABLE(#12093000) USE 12093045 |
| 27 | 12006500 | BAND (#12006500) |
| 28 | 95100137 | WASHER (#95100137) |
