1967 1968 V700 Gear Box Shafts Controls
| Position | Part Number | Description |
|---|---|---|
| 10 | 12250900 | RIGHT HAND SHIFT LEVER (#12250900) |
| 11 | 55251000 | RUBBER (#55251000) |
| 12 | 98052325 | BOLT (#98052325) |
| 12 | 98106022 | BOLT (#98106022) |
| 13 | 12251100 | SHAFT (#12251100) |
| 14 | 95500222 | SPLIT PIN (#95500222) |
| 15 | 95129110 | WASHER (#95129110) |
| 16 | 95780265 | PIN (#95780265) USE 95770265 |
| 17 | 11251900 | NUT (#11251900) |
| 18 | 95740171 | FORK (#95740171) |
| 19 | 12257900 | ROD (#12257900) |
| 20 | 12257800 | TIE ROD (#12257800) USE 12257801 |
| 21 | 98106021 | BOLT (98106021) (#98106021) |
| 22 | 12258200 | TIE ROD (#12258200) |
| 23 | 12236800 | SHAFT (#12236800) |
| 24 | 55238200 | SPRING (#55238200) |
| 25 | 12238500 | PLATE (#12238500) |
| 26 | 12234400 | SHIFT DRUM 4SPD (#12234400) |
| 27 | 55236400 | BODY SELECTOR (#55236400) |
| 28 | 55237900 | PAWL (#55237900) |
| 29 | 26267200 | PAWL (#26267200) |
| 30 | 94321049 | SPRING (#94321049) |
| 31 | 12234300 | ROD (#12234300) |
| 32 | 55235000 | SHIM 0.6MM (#55235000) |
| 32 | 55235001 | SHIM 0.8MM (#55235001) |
| 32 | 55235002 | SHIM 1.0MM (#55235002) |
| 32 | 55235003 | SHIM 1.2MM (#55235003) |
| 32 | 95100222 | WASHER (#95100222) |
| 33 | 12202000 | PLATE (#12202000) |
| 34 | 12232400 | SHAFT (#12232400) |
| 35 | 12230500 | FORK (#12230500) |
| 36 | 12210500 | MAINSHAFT (#12210500) |
| 37 | 90118245 | COPPER WASHER A (#90118245) |
| 38 | 12213600 | LAYSHAFT (#12213600) |
| 39 | 93601022 | LOCK RING (#93601022) |
| 40 | 95028022 | WASHER (#95028022) |
| 41 | 12215500 | SPACER (#12215500) |
| 42 | 12214300 | WASHER (#12214300) |
| 43 | 12214000 | GEAR (#12214000) |
| 44 | 91122720 | BUSHING (#91122720) |
| 45 | 90271027 | CIRCLIP (#90271027) |
| 46 | 12230700 | SLEEVE (#12230700) |
| 47 | 12214400 | GEAR 2ND W/O BUSHING (#12214400) |
| 48 | 91122716 | BUSHING (#91122716) |
| 49 | 12214700 | GEAR (#12214700) |
| 50 | 12231500 | SLEEVE (#12231500) |
| 51 | 12215100 | GEAR (#12215100) |
| 52 | 12215300 | FLOATING BUSH (#12215300) |
| 53 | 12210700 | 12210701 (#12210700) |
| 54 | 90271023 | CIRCLIP (#90271023) |
| 55 | 12081800 | 12081801 (#12081800) |
| 56 | 12211700 | HALF SECTOR (#12211700) |
| 57 | 12211600 | PLATE (#12211600) |
| 57 | 13211600 | PLATE (#13211600) |
| 58 | 12211500 | SPRING (#12211500) |
| 58 | 13211500 | SPRING (#13211500) |
| 59 | 12211200 | SLIDING YOKE (#12211200) |
| 60 | 12211100 | SLIDING YOKE (#12211100) |
