1967 1968 V700 Rear Wheel Hub Rear Brake And Control
| Position | Part Number | Description |
|---|---|---|
| 10 | 12630200 | 12630201 (#12630200) |
| 11 | 12630500 | REAR WHEEL (#12630500) |
| 12 | 12610800 | WHEEL RIM (#12610800) |
| 13 | 12611500 | SPOKE (#12611500) USE 12611501 OR 12611501A |
| 14 | 12633000 | BRAKE DRUM (#12633000) |
| 15 | 92700171 | NUT (#92700171) |
| 16 | 95100628 | WASHER (#95100628) |
| 17 | 12633300 | SPINDLE OR AXEL (#12633300) |
| 18 | 12634100 | SPACER (#12634100) |
| 19 | 12635200 | HUB COVER (#12635200) |
| 20 | 12637400 | BRAKE SHOE RR. PR. - (#12637400) NLA |
| 21 | 12621400 | BRAKE LINING (#12621400) |
| 22 | 12620900 | END PLATE (#12620900) |
| 23 | 98280614 | SCREW (#98280614) |
| 24 | 12938100 | Spring, brake shoe (#12938100) |
| 25 | 12636200 | PIN (#12636200) |
| 26 | 95100521 | WASHER (#95100521) |
| 27 | 92701148 | NUT (#92701148) |
| 28 | 12636600 | TIE ROD (#12636600) |
| 29 | 95021110 | WASHER (#95021110) |
| 30 | 92602210 | NUT (#92602210) |
| 31 | 98110015 | BOLT (#98110015) |
| 32 | 12622500 | CAM (#12622500) |
| 33 | 12639600 | LEVER (#12639600) |
| 34 | 98106022 | BOLT (#98106022) |
| 35 | 95730260 | THUMB SCREW (#95730260) |
| 36 | 95716365 | ROLLER (#95716365) |
| 37 | 95500222 | SPLIT PIN (#95500222) |
| 38 | 95100137 | WASHER (#95100137) |
| 39 | 12676000 | ROD (#12676000) |
| 40 | 12676500 | SPINDLE (#12676500) |
| 41 | 12677000 | LEVER (#12677000) |
| 42 | 95100727 | WASHER (#95100727) |
| 42 | 98022328 | SCREW (#98022328) |
| 42 | 98106028 | BOLT (#98106028) |
| 43 | 12678000 | SPRING (#12678000) |
| 44 | 92605008 | NUT (#92605008) |
| 45 | 95101231 | FLAT WASHER (#95101231) |
| 46 | 98108038 | BOLT (#98108038) |
| 47 | 12633200 | CENTRAL BODY (#12633200) |
| 48 | 90403249 | SEAL, HUB (#90403249) |
| 49 | 12615200 | bushing *NLA* (#12615200) |
| 50 | 92246922 | BEARING, TAPERED ROLLER (#92246922) |
| 51 | 95100715 | WASHER-ALL SIZE (#95100715) |
| 52 | 12634000 | SPACER (#12634000) |
