1969 1972 750 Ambassador Generator
| Position | Part Number | Description |
|---|---|---|
| - | 12700200 | GENERATOR (#12700200) |
| 1 | 12700223 | BOLT (#12700223) |
| 2 | 17700219 | End cover (#17700219) |
| 3 | 12700214 | WASHER (#12700214) |
| 4 | 12700217 | BALL BEARING (#12700217) |
| 5 | 12700216 | GREASE RETAINER (#12700216) |
| 6 | 12700259 | RING (#12700259) |
| 7 | 12700228 | Generator body c/w coils (#12700228) |
| 8 | 12700243 | WASHER (#12700243) |
| 9 | 12700226 | BALL BEARING (#12700226) |
| 10 | 12700260 | WASHER (#12700260) |
| 11 | 12700239 | BRUSH HOLDER (#12700239) |
| 12 | 25730739 | LOCK WASHER (#25730739) |
| 13 | 12700231 | COVER NUT (#12700231) |
| 14 | 12700225 | ARMATURE (#12700225) |
| 15 | 12700212 | CUP WASHER (#12700212) |
| 16 | 12700251 | Shim (0.1 mm) (#12700251) |
| 16 | 12700252 | SHIM (#12700252) |
| 17 | 12700253 | SPACER (#12700253) |
| 18 | 17700255 | Woodruff key (#17700255) |
| 19 | 12700254 | PULLEY W/FAN (#12700254) |
| 20 | 12700256 | WASHER (#12700256) |
| 21 | 12700257 | NUT (#12700257) |
| 22 | 12700247 | COIL (#12700247) |
| 23 | 12700258 | TERMINAL (#12700258) |
| 24 | 12700218 | COIL (#12700218) |
| 25 | 12700249 | POLE SHOE (#12700249) |
| 26 | 12700248 | SCREW (#12700248) |
| 27 | 12700227 | D.K. TERM SCREW (#12700227) |
| 28 | 12700246 | BLOCK (#12700246) |
| 29 | 12700241 | WASHER (#12700241) |
| 30 | 12730760 | WASHER (#12730760) |
| 31 | 12700236 | NUT (#12700236) |
| 32 | 12700224 | DOWEL (#12700224) |
| 33 | 12700244 | WASHER (#12700244) |
| 34 | 12700242 | WASHER (#12700242) |
| 35 | 12730723 | WASHER (#12730723) |
| 36 | 12700746 | NUT (#12700746) |
| 37 | 12700745 | Terminal end nut (#12700745) |
| 38 | 12700238 | BRUSH FOR MARELLI (#12700238) |
| 39 | 12700237 | SPRING (#12700237) |
| 39 | 12703801 | REGULATOR MARELLI NLA 7/98 (#12703801) |
| 40 | 12703802 | SCREW (#12703802) |
| 42 | 12703804 | SCREW (#12703804) |
| 43 | 12700735 | WASHER (#12700735) |
