1969 1972 750 Ambassador Handlebar And Controls
| Position | Part Number | Description |
|---|---|---|
| 10 | 12600101 | Handlebar, c/w levers (#12600101) |
| 11 | 12600300 | HANDLEBAR V700 AMB ELDO (CIV) NLA (#12600300) |
| 12 | 12605401 | LEVER ASSEMBLY 13605445 (#12605401) |
| 13 | 55605600 | BRAKE LEVER (#55605600) USE 12605605 |
| 14 | 12601000 | BRAKE LEVER PERCH OR BRACKET (#12601000) |
| 15 | 98326017 | SCREW CHROME (#98326017) |
| 16 | 95021106 | WASHER, WAVE (#95021106) |
| 17 | 92602406 | ADJ SCREW NUT (#92602406) |
| 18 | 95790237 | SCREW CABLE ADJ (#95790237) |
| 19 | 93760072 | CABLE ADJ. NUT (#93760072) |
| 20 | 98620330 | V/COVER BOLT (#98620330) USE 98680330 |
| 21 | 12605500 | CLUTCH LEVER ASSY (#12605500) USE 12605505 |
| 22 | 55605700 | CLUTCH LEVER (#55605700) |
| 23 | 12601900 | CL LEVER PERCH (#12601900) USE 12601905 |
| 24 | 98620318 | ALLEN BOLT (#98620318) USE 98622318 |
| 25 | 55603500 | #09 RH hand grip (#55603500) |
| 26 | 55603400 | THROTTLE CONTROL PIPE (#55603400) |
| 27 | 55603000 | GRIPS, ELDO, AMB. B&W (#55603000) |
| 28 | 12118000 | 12118005 NLA USE MAGURA REPLACEMENT 14AL7 (#12118000) |
| 29 | 98107017 | BOLT (#98107017) |
| 30 | 91180707 | SPACER (#91180707) |
| 31 | 12500240 | HANDLEBAR CLAMP (#12500240) |
| 32 | 98024420 | BOLT (#98024420) |
| 33 | 95021108 | WASHER (#95021108) |
| 34 | 11500700 | SCREW*NLA* (#11500700) |
| 35 | 45409701 | PLUG (#45409701) |
