1969 1972 750 Ambassador Starter Motor
| Position | Part Number | Description |
|---|---|---|
| - | 12730700 | 12730705 MARELLI STARTER (#12730700) |
| - | 12730701 | 12730705 (#12730701) |
| 10 | 12730711 | STARTER COVER (#12730711) |
| 10 | 13730711 | STARTER HOUSING A (#13730711) |
| 11 | 25730712 | WASHER (#25730712) |
| 11 | 25730715 | WASHER (#25730715) |
| 12 | 12730713 | WASHER (#12730713) |
| 14 | 12730754 | CIRCLIP (#12730754) |
| 15 | 12730717 | RING (#12730717) |
| 16 | 12730716 | BENDEX (#12730716) |
| 17 | 12730730 | SPINDLE (#12730730) |
| 18 | 12730735 | COTTER PIN (#12730735) |
| 19 | 25730728 | BLOCK (#25730728) |
| 20 | 12730721 | NOT AVAILABLE X (#12730721) |
| 21 | 12730741 | ***ARMTR**N/A (#12730741) |
| 22 | 25730743 | WASHER (#25730743) |
| 23 | 25730744 | WASHER (#25730744) |
| 24 | 12730742 | WASHER (#12730742) |
| 25 | 23730745 | Spring (#23730745) |
| 26 | 12730746 | END COVER (#12730746) |
| 26 | 13730746 | END COVER (#13730746) |
| 27 | 12730723 | WASHER (#12730723) |
| 28 | 12730715 | NUT (#12730715) |
| 29 | 12730726 | 13730726 (#12730726) |
| 29 | 13730726 | SOLENOID (#13730726) |
| 30 | 12730749 | BOLT (#12730749) |
| 31 | 12730751 | BUSHING (#12730751) |
| 32 | 12730755 | STUD (#12730755) |
| 33 | 12730756 | COIL (#12730756) |
| 34 | 12730772 | INSUL. RUBBER (#12730772) |
| 35 | 12730778 | COIL TERMINAL (#12730778) |
| 36 | 12730757 | SHOE (#12730757) |
| 37 | 25730758 | SCREW (#25730758) |
| 38 | 25730771 | 12730752 (#25730771) |
| 39 | 12730747 | STARTER BRUSH (#12730747) use 13730747 |
| 39 | 13730747 | BRUSH EACH (#13730747) |
| 40 | 25730748 | SPRING (#25730748) |
| 41 | 12730736 | NUT (#12730736) |
| 42 | 12730760 | WASHER (#12730760) |
| 43 | 25730751 | 12730751 (#25730751) |
| 44 | 12730764 | WASHER (#12730764) |
| 45 | 12730763 | WASHER (#12730763) |
| 46 | 12730740 | NUT (#12730740) |
| 47 | 12730765 | SCREW (#12730765) |
| 49 | 12730750 | 13730750 (#12730750) |
| 49 | 13730750 | CAP (#13730750) |
| 50 | 12730758 | (#12730758) USE 13730747 |
| 51 | 12730759 | WASHER (#12730759) |
| 52 | 12730761 | Spring washer (#12730761) |
| 53 | 13730779 | O RING (#13730779) |
