1972 1974 850 Eldorado Carburetor Control Cables Air Cleaner
| Position | Part Number | Description |
|---|---|---|
| 10 | ||
| 10 | ||
| 11 | 12114401 | TUBE OR VOLICITY STACK (#12114401) |
| 12 | 12607500 | CABLE THROTTLE (#12607500) |
| 13 | 12607900 | ADAPTER (#12607900) |
| 14 | 12807100 | JUNCTION BLOCK COVER (#12807100) |
| 15 | 12807000 | PLUNGER (#12807000) |
| 16 | 12807200 | JUNCTION BLOCK COVER (#12807200) |
| 17 | 98103015 | Screw, adaptor securing (#98103015) |
| 18 | 95101231 | FLAT WASHER (#95101231) |
| 19 | 92602208 | NUT (#92602208) |
| 20 | 95790233 | SCREW (#95790233) |
| 21 | 92700071 | NUT (#92700071) |
| 22 | 12608300 | CABLE CHOKE ELDO,AMB,V700 (#12608300) |
| 23 | 12117001 | CABLE CHOKE LOWER V700/AMB/ELD (#12117001) |
| 24 | 12117501 | THROTTLE CABLE V700,AMB,ELDO (#12117501) |
| 25 | 12113200 | AIR CLEANER BOX NLA (#12113200) |
| 26 | 12113600 | AIR FILTER (#12113600) |
| 27 | 12113401 | COVER (#12113401) |
| 28 | 98054312 | BOLT (#98054312) |
| 29 | 95021106 | WASHER, WAVE (#95021106) |
| 30 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 31 | 92602206 | NUT (#92602206) USE STHN6MM |
| 32 | 12114301 | SLEEVE, CARB (#12114301) |
