1972 1974 850 Eldorado Connecting Rods Crankshaft Piston Timing Gears
| Position | Part Number | Description |
|---|---|---|
| 10 | 13064260 | CRANKSHAFT (#13064260) |
| 10 | 91702355 | WOODRUFF KEY (#91702355) |
| 11 | 12065400 | CRANK PLUG (#12065400) |
| 12 | 14061501 | CON ROD (#14061501) |
| 13 | 91112122 | #14 Bushing (#91112122) |
| 14 | 92731090 | NUT (#92731090) |
| 15 | 14062201 | CONN.ROD BOLT USE 30062260 (#14062201) |
| 16 | 12062000 | HALF BEARING Use 01062030 (#12062000) |
| 16 | 12062001 | HALF BEARING USE 30062001 (#12062001) |
| 16 | 12062002 | ROD BEARING 1/2 (#12062002) |
| 16 | 12062003 | BEARING (#12062003) |
| 16 | 12062004 | 1/2 BEARING (#12062004) |
| 17 | ||
| 17 | 13060460 | PISTON (#13060460) |
| 18 | 13060700 | PISTON RING (#13060700) |
| 19 | 13060800 | PISTON RING (#13060800) |
| 20 | 13060900 | OIL SCRAPER (#13060900) |
| 21 | 13061260 | PISTON PIN (#13061260) |
| 22 | 90351037 | CIRCLIP USE 27061385 (#90351037) |
| 23 | 13071700 | GEAR SET (#13071700) |
| 24 | 90706250 | O RING (#90706250) |
| 25 | 13074060 | PULLEY (#13074060) |
| 26 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 27 | 95021106 | WASHER, WAVE (#95021106) |
| 28 | 92701187 | NUT (#92701187) |
| 29 | 95100676 | WASHER (#95100676) |
| 30 | 12067000 | FLYWHEEL (#12067000) |
| 31 | 12067600 | TAB (#12067600) USE 14615901 |
| 32 | 12067701 | SCREW (#12067701) use 597150 |
| 33 | 12067900 | RING GEAR 17067900 (#12067900) |
| 34 | 95120085 | WASHER (#95120085) |
| 35 | 98054425 | BOLT (#98054425) |
| 36 | 12053302 | SHAFT (#12053302) |
| 37 | ||
| 38 | 95120065 | WASHER (#95120065) |
| 38 | 98106021 | BOLT (98106021) (#98106021) |
| 39 | 95512060 | PIN ROLLER (#95512060) |
| 40 | 12045800 | TAPPET OR LIFTER (#12045800) |
| 40 | 12045801 | TAPPET (#12045801) |
| 40 | 12045802 | TAPPET (#12045802) |
| 41 | 12045001 | PUSH ROD (#12045001) |
