1972 1974 850 Eldorado Cylinder Head And Valves
| Position | Part Number | Description |
|---|---|---|
| 10 | 12023502 | VALVE COVER (#12023502) |
| 11 | 12023700 | V/C GASKET (#12023700) |
| 12 | 98620330 | V/COVER BOLT (#98620330) USE 98680330 |
| 13 | 13022160 | RH CYL.HEAD (#13022160) |
| 13 | 13022260 | LH CYL. HEAD (#13022260) |
| 14 | 13036800 | VALVE GUIDE (#13036800) USE 13036801A |
| 15 | 13036900 | VALVE GUIDE (#13036900) USE 13036801 |
| 16 | 90353016 | VALVE GUIDE CLIP (#90353016) |
| 17 | 12038100 | HALF CONE (#12038100) |
| 18 | 13038000 | TOP COLLAR (#13038000) |
| 19 | 13037400 | OUTER SPRING (#13037400) |
| 20 | 13037600 | INNER SPRING (#13037600) |
| 21 | 13037000 | PLATE (#13037000) |
| 22 | 13037200 | WASHER (#13037200) |
| 23 | 13036000 | INTAKE VALVE (#13036000) use 29036050 |
| 24 | 13036100 | EX VALVE (#13036100) |
| 25 | 12034800 | SUPPORT (#12034800) |
| 26 | 12030200 | ROCKER ARM/RIGHT SIDE (#12030200) |
| 27 | 12030400 | ROCKER ARM/LEFT SIDE (#12030400) |
| 28 | 91111511 | ROCK.ARM BSHG. (#91111511) |
| 29 | 12034001 | SCREW (#12034001) |
| 30 | ||
| 31 | 12031800 | ROCKER SPINDLE (#12031800) |
| 32 | 90118152 | WASHER (#90118152) |
| 33 | 94322215 | SPRING-ROCKER (#94322215) |
| 34 | 98024312 | BOLT (#98024312) |
| 35 | 95120065 | WASHER (#95120065) |
| 36 | 13022001 | HEAD GASKET (#13022001) |
| 37 | 13020200 | CYLINDER (#13020200) |
| 38 | 13028000 | Gasket, cylinder base (#13028000) |
| 39 | 12021700 | BOLT-ROD (#12021700) |
| 40 | 90706090 | O RING (#90706090) USE 90706094 |
| 41 | 14018400 | WASHER (#14018400) |
| 42 | 92751103 | NUT (#92751103) |
| 43 | 12021800 | BOLT (#12021800) |
| 44 | 95129180 | WAVE WASHER (#95129180) |
| 45 | ||
| 46 | 95100709 | CRUSH WASHER (95100709) (#95100709) |
| 47 | 95980120 | PLUG (#95980120) |
| 48 | 98620435 | SCREW USE 9868 0435 (#98620435) |
| 49 | 90716082 | USE 90716083 (#90716082) |
| 50 | 95100223 | WASHER (#95100223) |
| 51 | 12115002 | MANIFOLD (#12115002) USE 12115004 |
| 51 | 12115003 | 12115005 (#12115003) |
| 52 | 12115503 | MANIFOLD GASKET (#12115503) USE 14115500 |
| 52 | 13060160 | CYL & PIST.3 RING ELDO (#13060160) |
| 53 | 14115400 | WIRE GUIDE (#14115400) USE 14115401 |
| 54 | 91551081 | GROMMET (#91551081) |
