1972 1974 850 Eldorado Front Fork Front Fender Steering
| Position | Part Number | Description |
|---|---|---|
| 4 | 98054312 | BOLT (#98054312) |
| 10 | 12490221 | FORK (#12490221) |
| 11 | 92701139 | NUT (#92701139) |
| 12 | 95100521 | WASHER (#95100521) |
| 13 | 12504500 | PLUG (#12504500) |
| 14 | 90706222 | O RING (#90706222) |
| 15 | ||
| 16 | 12493001 | PLATE (#12493001) |
| 17 | ||
| 18 | 12492300 | CAP (#12492300) |
| 19 | 93601025 | NUT (#93601025) USE 93601026 |
| 20 | 12494500 | CAP (#12494500) |
| 20 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 22 | 12494180 | STEM (#12494180) |
| 23 | ||
| 24 | 12494201 | BOTTOM YOKE (#12494201) |
| 25 | 95101430 | WASHER (#95101430) |
| 25 | 98053675 | BOLT (#98053675) |
| 27 | 92602512 | NUT (#92602512) |
| 28 | 12498000 | GUIDING SQUARE (#12498000) |
| 29 | 91551102 | GROMMET (#91551102) |
| 30 | 12496121 | H.L. BRACKET RH (#12496121) |
| 31 | 12496221 | H.L. BRACKET LH (#12496221) |
| 32 | 12527600 | BOTTOM PLATE (#12527600) |
| 33 | 12526600 | SPRING (#12526600) |
| 34 | 12527700 | HOUSING (#12527700) |
| 35 | 90403550 | SEALS, F/FORKS (#90403550) |
| 36 | 12555400 | Fork tube (#12555400) |
| 37 | 12525900 | LOCK RING (#12525900) |
| 37 | 95100901 | SPACER (#95100901) |
| 38 | 12525800 | BUSHING NLA (#12525800) |
| 39 | 12522500 | FORK LEG RH (#12522500) |
| 40 | 12522800 | Cover, fork, L/H (#12522800) |
| 41 | 90706490 | O RING (#90706490) |
| 42 | 12527210 | SHIM 0.1 MM (#12527210) |
| 43 | 90353046 | CIRCLIP (#90353046) |
| 44 | 12527200 | SHIM 2.0 MM (#12527200) |
| 44 | 12527201 | SHIM 2.1 MM (#12527201) |
| 44 | 12527202 | SHIM 2.2 MM (#12527202) |
| 44 | 12527203 | SHIM 2.3 MM (#12527203) |
| 44 | 12527204 | SHIM 2.4 MM (#12527204) |
| 45 | 12526700 | BUSHING (#12526700) |
| 46 | 98020535 | BOLT (#98020535) |
| 47 | 95100331 | WASHER NLA (#95100331) |
| 48 | 98305009 | SCREW (#98305009) |
| 49 | 90714051 | WASHER 5.25 X 8.5 X 1 (#90714051) |
| 50 | 13434320 | 12434320=4365 (#13434320) |
| 51 | ||
| 52 | 12435700 | FRONT FENDER STAY TOP V700 AMBASSADOR ELDORADO (#12435700) |
| 53 | 12435900 | FRONT FENDER STAY REAR (#12435900) |
| 55 | 95100121 | WASHER (#95100121) |
| 56 | 55434825 | PLATE (#55434825) |
| 57 | 95100130 | WASHER (#95100130) |
| 58 | 98024422 | BOLT (#98024422) |
| 59 | 95021108 | WASHER (#95021108) |
| 60 | 92602208 | NUT (#92602208) |
| 61 | 93180105 | PLUG (#93180105) |
| 62 | 13436561 | CABLE HOLDER (#13436561) |
| 63 | 12781621 | USE 12781521 REFLEX REFLECTO AMBER NLA (#12781621) |
| 64 | 14517000 | RING DUST SEAL (#14517000) |
| 65 | 93110060 | RUBBER WASHER (#93110060) |
| 66 | 95000205 | WASHER (#95000205) |
| 67 | 92630105 | NUT (#92630105) |
