1972 1974 850 Eldorado Gearbox Gears And Shafts Controls
| Position | Part Number | Description |
|---|---|---|
| 10 | 12250906 | PEDAL LH SHIFT NLA (#12250906) |
| 11 | 55251000 | RUBBER (#55251000) |
| 12 | 98054425 | BOLT (#98054425) |
| 13 | ||
| 13 | 12442105 | RUBBER BUSH NLA 10/23/02 (#12442105) |
| 13 | 13251165 | SHAFT(#13251165) |
| 14 | 13250760 | SPACER (#13250760) |
| 15 | 95500222 | SPLIT PIN (#95500222) |
| 16 | 95129110 | WASHER (#95129110) |
| 17 | 95780265 | PIN (#95780265) USE 95770265 |
| 18 | 92700073 | NUT (#92700073) |
| 19 | 95740171 | FORK (#95740171) |
| 20 | ||
| 21 | 13257860 | TIE ROD (#13257860) |
| 22 | 98052325 | BOLT (#98052325) |
| 23 | 95021106 | WASHER, WAVE (#95021106) |
| 24 | 13258260 | LEVER (#13258260) |
| 25 | 14236201 | 6202-PRE-SELECT (#14236201) |
| 27 | 14236600 | SPINDLE (#14236600) |
| 28 | 10237900 | PAWL (#10237900) |
| 29 | 10238300 | SPRING (#10238300) |
| 30 | 95520314 | DOWEL (#95520314) |
| 31 | 14238200 | RETURN SPRING (#14238200) |
| 32 | 14234400 | 4401-DRUM (#14234400) |
| 32 | 14234600 | PIN (#14234600) |
| 33 | 14235500 | WASHER (#14235500) |
| 34 | 14234300 | ROD (#14234300) |
| 35 | 55235000 | SHIM 0.6MM (#55235000) |
| 35 | 55235001 | SHIM 0.8MM (#55235001) |
| 35 | 55235002 | SHIM 1.0MM (#55235002) |
| 35 | 55235003 | SHIM 1.2MM (#55235003) |
| 36 | 14232400 | ROD (#14232400) |
| 37 | 14230501 | SLIDING FORK (#14230501) |
| 38 | 14231201 | SHIFT FORK (#14231201) |
| 39 | 14210511 | 14210513 (#14210511) |
| 40 | 12211000 | SHIM 2.0MM (#12211000) |
| 40 | 12211001 | SHIM 2.1MM (#12211001) |
| 40 | 12211002 | SHIM 2.2MM (#12211002) |
| 40 | 12211004 | SHIM (#12211004) |
| 41 | 90118247 | WASHER (#90118247) |
| 42 | 14212010 | GEAR (#14212010) |
| 43 | 14213000 | BUSHING (#14213000) |
| 44 | 92251030 | CAGE (#92251030) |
| 45 | 14212210 | BUSH (#14212210) |
| 46 | 92296750 | ROLLER (#92296750) |
| 47 | 94321051 | SPRING (#94321051) |
| 48 | 14231510 | SLEEVE (#14231510) |
| 49 | 14213610 | SHAFT (#14213610) |
| 50 | 14214510 | GEAR USE 2821 4587 Z=24 (#14214510) |
| 51 | 14214810 | GEAR 3RD GEAR (#14214810) |
| 52 | 14218010 | WASHER (#14218010) |
| 53 | 14232510 | SLEEVE (#14232510) |
| 54 | 14231010 | 14231012 (#14231010) |
| 55 | 14215110 | GEAR 4TH (#14215110) |
| 55 | 92259017 | RACE (#92259017) |
| 57 | 92251022 | CAGE-BUSHING (#92251022) |
| 58 | 14215400 | WASHER (#14215400) |
| 59 | 43083810 | ADJUSTING WASHER (#43083810) |
| 60 | 14217410 | LOCK NUT (#14217410) |
| 61 | 14215210 | GEAR (#14215210) |
| 62 | 90706203 | O RING (#90706203) |
| 63 | 14217300 | SHIM (#14217300) |
| 64 | ||
| 65 | 14214210 | GEAR 1ST (#14214210) |
| 66 | 14230710 | 14230711 (#14230710) |
| 67 | 14081810 | CLUTCH HUB (#14081810) use 30081810 |
| 68 | 93601022 | LOCK RING (#93601022) |
| 69 | 95028022 | WASHER (#95028022) |
| 70 | 14210701 | MAINSHAFT #14210701 (#14210701) |
| 71 | 14218401 | WASHER (#14218401) |
| 72 | 90706235 | O RING (#90706235) |
| 73 | 14211110 | GEAR (#14211110) |
| 74 | 12211200 | SLIDING YOKE (#12211200) |
| 75 | 13211500 | SPRING (#13211500) |
| 76 | 13211600 | PLATE (#13211600) |
| 77 | 12211700 | HALF SECTOR (#12211700) |
| 78 | 14219401 | SPACER (#14219401) |
| 79 | 92295702 | BALL (#92295702) |
