1974 1975 850 T Carburetor
| Position | Part Number | Description |
|---|---|---|
| 1 | 14112602 | CARB. RH (#14112602) |
| 1 | 14112603 | CARB. LH (#14112603) |
| 2 | 13937000 | PROTECT CAP CABLE BOOT (#13937000) |
| 3 | 13932800 | SCREW NLA (#13932800) |
| 4 | 13932900 | WASHER (#13932900) |
| 5 | 12937200 | CABLE ADJUSTER (#12937200) |
| 6 | 12937300 | NUT (#12937300) |
| 7 | 13935000 | COVER (#13935000) |
| 8 | ||
| 9 | 13937100 | SPRING (#13937100) |
| 10 | 14937501 | THROTTLE SLIDE (#14937501) |
| 11 | 14937701 | Slide Needle V9 (#14937701) |
| 12 | 55938585 | NEEDLE CLIP (#55938585) |
| 13 | 13937900 | SCREW (#13937900) |
| 14 | 14937800 | STARTER CHOKE VHB and PHF 30 and 36mm (#14937800) |
| 15 | 14938300 | O RINGS (#14938300) USE 17937550 |
| 16 | 13933700 | CARB BOWL NUT (#13933700) |
| 17 | 13933900 | WASHER (#13933900) |
| 18 | 13934400 | BODY (#13934400) |
| 19 | 13933400 | O RING for Float Bowl (#13933400) |
| 20 | 14933000 | FLOATS - ALL BIG BLOCK (#14933000) |
| 21 | 13933100 | FLOAT PIN (13933100) (#13933100) |
| 22 | 13934800 | FLOAT NEEDLE VALVE (#13934800) |
| 23 | 14935701 | 1486142 (#14935701) |
| 25 | 13935500 | ATOMIZER #265 FOR VHB (#13935500) |
| 26 | 10935900 | JET (#10935900) #50. USE 148650 |
| 27 | 13936000 | START JET #80 (#13936000) |
| 28 | 13936100 | O RING (#13936100) |
| 29 | 13936600 | SCREW (#13936600) |
| 30 | 13936700 | SPRING (#13936700) |
| 31 | 13936200 | SCREW (#13936200) |
| 32 | 13936300 | SPRING (#13936300) |
| 33 | 14936800 | NUT (#14936800) |
| 34 | 14938600 | SCREW (#14938600) |
| 35 | 14938700 | RING (#14938700) |
| 36 | 14938900 | INSUL. BUSHING USE 17938960 (#14938900) |
| 37 | 13934900 | BOLT (#13934900) USE 10934900 |
| 38 | 13934700 | FIBER WASHERS (#13934700) |
| 39 | 13934600 | CARB.ADAPTER BLACK PLASTIC (#13934600) |
| 40 | 43934000 | Fuel Filter Screen (43934000) (#43934000) |
| 89 | ||
| 90 | 17939000 | PUMP PLUNGER (#17939000) |
| 91 | 17939100 | BALL VALVE (#17939100) |
| 92 | 17939200 | VALVE SEAT (#17939200) |
| 93 | 17939300 | SPRING (#17939300) |
| 94 | 17939400 | JET HOLDER (#17939400) |
