1974 1975 850 T Front And Rear Suspensions
| Position | Part Number | Description |
|---|---|---|
| 1 | 17490200 | 17490220 (#17490200) |
| 1 | 17490202 | Front Fork (#17490202) |
| 1 | 17490220 | 17490201 (#17490220) |
| 2 | 14504502 | PLUG (#14504502) |
| 3 | 90706238 | O RING (#90706238) |
| 4 | 98622535 | SCREW (#98622535) |
| 5 | 17493100 | UPPER PLATE (#17493100) |
| 6 | 17516600 | BUSHING 1451 6600 (#17516600) |
| 7 | 17517700 | DISC 1415 6600 (#17517700) |
| 8 | ||
| 9 | 10513401 | NUT (#10513401) |
| 10 | 10494600 | 14494600 (#10494600) |
| 11 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 12 | 14516700 | SHIM (#14516700) |
| 13 | 14517000 | RING DUST SEAL (#14517000) |
| 14 | 14494002 | 17494000 (#14494002) |
| 14 | 17494000 | (#17494000) USE 17494001 |
| 15 | 98622422 | SCREW (#98622422) |
| 17 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 18 | 98620540 | SCREW (#98620540) |
| 19 | 92602210 | NUT (#92602210) |
| 20 | 14522502 | 17522520 (#14522502) |
| 20 | 17522520 | FORK LEG RH (#17522520) |
| 21 | 14522602 | 17522620 (#14522602) |
| 21 | 17522620 | FORK LEG LH (#17522620) |
| 22 | 98620312 | OIL DRAIN PLUG ALLEN BOLT (#98620312) |
| 23 | 95100116 | WASHER (#95100116) |
| 24 | 14524500 | FORK DUST COVERS (#14524500) |
| 25 | 90272047 | CIRCLIP (#90272047) |
| 26 | 90403547 | FORK SEAL- (#90403547) USE 90403449 |
| 27 | 14525401 | FORK TUBE (#14525401) |
| 28 | 14526407 | DAMPER (#14526407) |
| 29 | 92630106 | NUT USE 92630707 (#92630106) |
| 30 | 14526505 | RUBBER RING (#14526505) |
| 31 | 14527800 | TUBE (#14527800) |
| 32 | 14527900 | CUP (#14527900) |
| 33 | 14526600 | SPRING EACH (#14526600) |
| 34 | 90271014 | RING USE 90271015 (#90271014) |
| 35 | 14527600 | NUT (#14527600) USE 18527950 |
| 36 | 17496100 | HL BRACKET RH {62496200} (#17496100) |
| 37 | 17496200 | HL BRACKET LH USE 62496100 (#17496200) |
| 38 | ||
| 39 | 17550200 | 18550250 (#17550200) |
| 40 | 17550300 | COVER (#17550300) |
| 41 | 17552300 | SHOCK SPRING (#17552300) |
| 42 | 17551600 | RUBBER SHOCK BUSHING (#17551600) |
| 43 | 95005215 | WASHER (#95005215) USE 95004215 |
| 44 | 95110337 | WASHER CHROME (#95110337) |
| 45 | 92603210 | NUT (#92603210) |
| 46 | 95110255 | WASHER (#95110255) |
| 47 | 98064416 | BOLT (#98064416) |
