1974 1975 850 T Lighting Horn
| Position | Part Number | Description |
|---|---|---|
| 1 | 17740501 | HEADLAMP A (#17740501) |
| 1 | 17740520 | H.L. COMPLETE (#17740520) |
| 2 | 93450231 | BULB (#93450231) |
| 3 | 93450119 | BULB 12V (#93450119) USE 163015 |
| 4 | 14743700 | HORN (#14743700) |
| 4 | 14743701 | HORN (#14743701) |
| 5 | 98052435 | BOLT (#98052435) |
| 6 | 95021108 | WASHER (#95021108) |
| 8 | 17743000 | FUSE BLOCK (#17743000) |
| 9 | 55742526 | FUSE (#55742526) |
| 10 | 14740130 | FUSE (#14740130) USE 12742500 |
| 11 | 98202530 | SCREW (#98202530) |
| 12 | 95000205 | WASHER (#95000205) |
| 13 | 92630105 | NUT (#92630105) |
| 14 | 14474901 | LAMP (#14474901) |
| 14 | 17744920 | TAIL LIGHT AFTMKT LENS (#17744920) use (01697) |
| 15 | 93450224 | BULB T.L. (#93450224) |
| 16 | 91551081 | GROMMET (#91551081) |
| 17 | 10475900 | GASKET (#10475900) |
| 18 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 19 | 95000206 | WASHER (#95000206) |
| 20 | 92630106 | NUT USE 92630707 (#92630106) |
| 21 | 10474600 | PLATE (#10474600) |
| 23 | 95100141 | WASHER (#95100141) |
| 24 | 93110060 | RUBBER WASHER (#93110060) |
| 25 | 98054220 | BOLT (#98054220) |
| 26 | 95100059 | WASHER (#95100059) |
| 27 | 95021105 | LOCK WASHER (#95021105) |
| 29 | 93301313 | BRACKET (#93301313) |
| 30 | 14741110 | STOP SWITCH (#14741110) |
| 31 | 14743200 | SPRING (#14743200) |
| 32 | ||
| 34 | 92602206 | NUT (#92602206) USE STHN6MM |
| 35 | 17747100 | ***H/NESS**N/A USE 17747150 T3 HAS EXTRA WIRES (#17747100) |
| 36 | 12708541 | HORN RELAY (#12708541) |
| 37 | 95100121 | WASHER (#95100121) |
| 38 | 95021106 | WASHER, WAVE (#95021106) |
| 39 | 17751600 | NOT AVAILABLE X (#17751600) |
| 39 | 17751620 | FLASHER (#17751620) |
| 40 | 93450129 | BULB (#93450129) |
| 41 | 91181005 | SPACER (#91181005) |
| 42 | 14018400 | WASHER (#14018400) |
| 43 | 92602210 | NUT (#92602210) |
| 44 | 17750500 | FLASHER (#17750500) |
| 44 | 17750520 | TURN SIGNAL FLASHER (#17750520) |
| 45 | 17751200 | FLASHER HOLDER (#17751200) |
| 46 | 17750400 | RELAY BRACKET (#17750400) |
| 47 | 13609660 | 14609650 (#13609660) |
| 48 | 17756200 | TERMINAL BLOCK (#17756200) |
| 49 | 17756100 | TERMINAL BLOCK (#17756100) |
| 50 | 17756000 | COVER (#17756000) |
| 51 | 12735100 | CAP (#12735100) |
| 52 | 12750605 | T/SIG VIN 003 ***NLA*** (#12750605) |
| 52 | 13750660 | DIRECT. LIGHT (#13750660) |
| 53 | 17753320 | TURN SIG STEM (#17753320) |
| 54 | 95004210 | WASHER (#95004210) |
| 55 | 12753705 | T/S LENS LUCAS ORIGINAL (#12753705) |
| 55 | 13753760 | APRILIA TURN SIGNAL LENS ***N/A*** 6/20/01 (#13753760) |
| 55 | 14999001 | GASKET SET COMPLETE BIKE (#14999001) |
| 55 |
