1974 1975 850 T Rear Fork And Reardrive
| Position | Part Number | Description |
|---|---|---|
| 1 | 12540200 | REAR FORK (#12540200) |
| 2 | 98062535 | BOLT (#98062535) |
| 3 | 95005210 | WASHER (#95005210) |
| 4 | 14547800 | NUT (#14547800) |
| 5 | 12547200 | SPACER (#12547200) |
| 6 | 14547000 | PIN (#14547000) USE 14547001 |
| 7 | 90403040 | SEAL, REAR FORK SPINDLE (#90403040) |
| 8 | 92249216 | BEARING (#92249216) USE 92249217 |
| 9 | 12548000 | BOOT, U-JOINT (#12548000) |
| 10 | 12548401 | CLAMP (#12548401) USE 93306050 |
| 11 | ||
| 12 | ||
| 13 | 90272058 | CIRCLIP (#90272058) |
| 14 | 92204228 | BEARING (#92204228) |
| 15 | 13350260 | REAR DRIVE BOX (#13350260) |
| 16 | 13350360 | REAR DRIVE BOX (#13350360) |
| 17 | 13351560 | COVER (#13351560) |
| 18 | 12351601 | GASKET (#12351601) |
| 19 | 98622320 | SCREW (#98622320) |
| 20 | 96508045 | SCREW (#96508045) |
| 21 | 95120085 | WASHER (#95120085) |
| 22 | 92602208 | NUT (#92602208) |
| 23 | 12003702 | DRAIN PLUG MAGNETIC (#12003702) |
| 24 | 95100709 | CRUSH WASHER (95100709) (#95100709) |
| 25 | 95980610 | PLUG (#95980610) |
| 26 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 27 | 12555201 | BOTTOM PIN (#12555201) |
| 28 | 90403850 | SEAL (#90403850 ) |
| 29 | 12351100 | RING COPPER METAL SPACER (#12351100) |
| 30 | ||
| 31 | 12311300 | Stop Plate (#12311300) |
| 32 | 98280614 | SCREW (#98280614) |
| 33 | 12352900 | GASKET (#12352900) |
| 34 | 12326300 | SHAFT (#12326300) |
| 35 | 12327700 | SLEEVE (#12327700) |
| 36 | 90271020 | CIRCLIP (#90271020) |
| 37 | 12356700 | LOCK NUT (#12356700) |
| 38 | 62249225 | Roller Bearing (#62249225) |
| 39 | 12352400 | HOUSING (#12352400) |
| 40 | 12352600 | GASKET (#12352600) |
| 41 | 90706490 | O RING (#90706490) |
| 42 | 12355100 | SPACER (#12355100) |
| 43 | 12355202 | SHIM 0.10MM (#12355202) |
| 43 | 12355203 | SHIM 0.15MM (#12355203) |
| 44 | 12355301 | SHIM 1.0MM (#12355301) |
| 44 | 12355302 | SHIM 1.2MM (#12355302) |
| 44 | 12355303 | SPACER (#12355303) |
| 45 | 98054425 | BOLT (#98054425) |
| 46 | 95004208 | WASHER (#95004208) |
| 47 | 95187008 | LOCK PLATE (#95187008) USE 1461 5901 |
| 48 | 12350400 | FLANGE (#12350400) |
| 49 | 12350700 | GASKET (#12350700) |
| 50 | 12355400 | SHIM 0.8MM (#12355400) |
| 50 | 12355402 | SHIM 0.9MM (#12355402) |
| 50 | 12355405 | Shim (#12355405) |
| 50 | 12355406 | SHIM 1.1MM (#12355406) |
| 50 | 12355408 | SHIM 1.2MM (#12355408) |
| 50 | 12355410 | SHIM 1.3MM (#12355410) |
| 51 | 92291070 | 92201070 (#92291070) |
| 52 | 90407085 | REAR DRIVE SEAL OUTPUT TO WHEEL (90407085) USE 9041 7085 (#90407085) |
| 53 | 12351400 | JOURNAL BEARING (#12351400) |
| 54 | 12354600 | RING GEAR SET 8X37 (#12354600) |
| 55 | 12356300 | SCREW (#12356300) |
| 56 | 12356400 | PLATE (#12356400) |
