1974 1975 850 T Rear Wheel
| Position | Part Number | Description |
|---|---|---|
| 1 | 17630200 | REAR WHEEL COMP (#17630200) |
| 2 | 17630600 | REAR WHEEL BARE (#17630600) |
| 3 | 12616101 | BALANCE WEIGHT (#12616101) |
| 3 | 12616102 | BALANCE WEIGHT 20 GRAMS (28 GRAMS=1 OZ) (#12616102) |
| 3 | 12616103 | BALANCE WEIGHT (#12616103) |
| 4 | 12611501 | SPOKE W/O NIPPLE (#12611501) |
| 5 | 17630700 | 12610800 (#17630700) |
| 6 | 14633003 | 3103-HUB (#14633003) |
| 7 | 98054314 | SCREW (#98054314) |
| 8 | 95021106 | WASHER, WAVE (#95021106) |
| 9 | 14335903 | PLATE (#14335903) |
| 10 | 14335303 | RING (#14335303) |
| 11 | 14335203 | HUB (#14335203) |
| 12 | 14336803 | CUSH DRIVE RUBBER (#14336803) |
| 13 | 90706490 | O RING (#90706490) |
| 14 | 92603316 | AXLE NUT (#92603316) use 92602316 |
| 15 | 14634400 | RING (#14634400) |
| 16 | 12634100 | SPACER (#12634100) |
| 17 | 14633301 | AXLE (#14633301) |
| 18 | 14635203 | COVER - BACKING PLATE (#14635203) |
| 19 | 14622805 | BUSHING (#14622805) |
| 20 | 17637400 | BR. SHOE (PR) (#17637400) USE 1462 0805 OR FSB796 |
| 21 | 14622005 | FRT. BR. LINING (#14622005) |
| 22 | 90271012 | SNAP RING (#90271012) |
| 23 | ||
| 24 | 17635003 | BRAKE CAM (#17635003) |
| 25 | 14639603 | LEVER (#14639603) |
| 26 | 12625000 | LEVER (#12625000) |
| 27 | 98062325 | BOLT (#98062325) |
| 28 | 13626660 | ROD COMPLETE (#13626660) |
| 29 | 13626760 | ROD (#13626760) |
| 30 | 13626860 | FORK (#13626860) |
| 31 | 92603206 | NUT (#92603206) |
| 32 | 95770265 | PIN (#95770265) |
| 33 | 95500222 | SPLIT PIN (#95500222) |
| 34 | 12636600 | TIE ROD (#12636600) |
| 35 | 98052535 | BOLT (#98052535) |
| 36 | 95021110 | WASHER (#95021110) |
| 37 | 98054520 | BOLT (#98054520) |
| 38 | 92602210 | NUT (#92602210) |
| 39 | 14634103 | SPACER (#14634103) |
| 40 | 90403247 | SEAL (#90403247) |
| 41 | 92201220 | BEARING (#92201220) |
| 42 | 14634003 | SPACER (#14634003) |
