1974 1975 850 T Transmission And Rear Brake Controls
| Position | Part Number | Description |
|---|---|---|
| 1 | 14258200 | LEVER GEAR SELE (#14258200) |
| 2 | 98052325 | BOLT (#98052325) |
| 3 | 95021106 | WASHER, WAVE (#95021106) |
| 4 | 17257800 | USE 14257901 (#17257800) |
| 5 | 12626800 | FORK (#12626800) |
| 6 | 92602206 | NUT (#92602206) USE STHN6MM |
| 7 | 95000206 | WASHER (#95000206) |
| 8 | 95500222 | SPLIT PIN (#95500222) |
| 9 | 95129110 | WASHER (#95129110) |
| 10 | 95780265 | PIN (#95780265) USE 95770265 |
| 11 | ||
| 12 | 14251001 | SHIFT AND BRAKE PEDAL RUBBER (#14251001) |
| 13 | 90716135 | RUBBER RING (#90716135) |
| 14 | 95004213 | WASHER (#95004213) |
| 15 | 94321138 | SPRING (#94321138) |
| 16 | 14259900 | RING (#14259900) |
| 17 | 14977005 | Rear Brake Lever (#14977005) |
| 18 | 98054425 | BOLT (#98054425) |
| 19 | 14251000 | RUBBER (#14251000) |
| 20 | 90716139 | RUBBER RING (#90716139) |
| 21 | ||
| 22 | 14677200 | RUBBER (#14677200) |
| 23 | 14678600 | CLAMP (#14678600) |
| 24 | 13676060 | ROD (#13676060) |
| 25 | 95717368 | PIN (#95717368) |
| 26 | 95732260 | ADJUSTER NUT CH (#95732260) |
