1976 1981 1000 Convert Clutch
| Position | Part Number | Description |
|---|---|---|
| 1 | 18245350 | FLANGED SHAFT (#18245350) |
| 2 | 18245550 | BUSHing (#18245550) |
| 3 | 90706600 | O RING (#90706600) |
| 4 | 18246250 | FLANGE (#18246250) |
| 5 | 90402535 | SEAL TRANSMISSION SEAL (#90402535) |
| 6 | 92201220 | BEARING (#92201220) |
| 7 | 90271020 | CIRCLIP (#90271020) |
| 8 | 90706158 | O RING (#90706158) |
| 9 | 90706473 | O RING (#90706473) |
| 10 | 98054320 | BOLT (#98054320) |
| 11 | 95021106 | WASHER, WAVE (#95021106) |
| 12 | 18245850 | SHAFT W/DRUM (#18245850) |
| 13 | 18082050 | RETAINING RING (#18082050) |
| 14 | 18082450 | PLATE (#18082450) |
| 15 | 18082350 | CLUTCH PLATE CONVERT (#18082350) |
| 16 | 61082200 | PLATE (#61082200) |
| 17 | 18081650 | PLATE (#18081650) |
| 18 | 61083800 | SHIM (#61083800) |
| 19 | 13084100 | CLUTCH SPRING (#13084100) |
| 20 | 18217450 | NUT (#18217450) |
| 21 | 90706188 | O RING (#90706188) |
| 22 | 18080350 | CL HOUSING (#18080350) |
| 23 | 18085250 | ROD (#18085250) |
| 24 | 18085850 | BUSHING (#18085850) |
| 25 | 92204217 | BALL BEARING, REAR WHEEL (#92204217) |
| 26 | 18210750 | CLUTCH SHAFT (#18210750) |
| 27 | 94321105 | SPRING (#94321105) |
| 28 | 18090250 | LEVER (#18090250) |
| 29 | 95780275 | PIN (#95780275) |
| 30 | 95500222 | SPLIT PIN (#95500222) |
| 31 | 18091350 | ADJUSTER NUT (#18091350) |
| 32 | 92602206 | NUT (#92602206) USE STHN6MM |
| 33 | 18093150 | PROTECTIVE CAP (#18093150) |
| 34 | 18210550 | MAINSHAFT (#18210550) |
| 35 | 92258525 | BEARING (#92258525) use 976532 |
| 36 | 18211050 | SHIM 2.0 (#18211050) |
| 36 | 18211051 | SHIM 2.1 (#18211051) |
| 36 | 18211052 | SHIM 2.2 (#18211052) |
| 36 | 18211054 | SHIM 2.4 (#18211054) |
| 37 | 18213550 | LAYSHAFT (#18213550) |
| 38 | 18214050 | LOW SPEED GEAR (#18214050) |
| 39 | 18214150 | L.S. BUSHING (#18214150) |
| 40 | 18214550 | GEAR (#18214550) |
| 41 | 18214950 | 18214951 (#18214950) |
| 42 | 18214650 | FRONT SHIM (#18214650) |
| 43 | 18215450 | REAR SHIM (#18215450) |
| 44 | 90706222 | O RING (#90706222) |
| 45 | 18213750 | SPACER (#18213750) |
| 46 | 90271122 | SNAP RING (#90271122) |
| 47 | 18233450 | SELECTOR FORK (#18233450) |
| 48 | 90706108 | O RING (#90706108) |
| 49 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 51 | 18233550 | SELECTOR SHAFT (#18233550) |
| 52 | 18257850 | DRAG LINK COMPL (#18257850) |
| 53 | 18257950 | DRAG LINK ROD (#18257950) |
| 54 | 12626800 | FORK (#12626800) |
| 56 | 95780265 | PIN (#95780265) USE 95770265 |
| 57 | 95129110 | WASHER (#95129110) |
| 58 | 18256950 | CONTROL LEVER (#18256950) |
| 59 | 17252050 | BUSH (#17252050) |
| 60 | ||
| 61 | 17252750 | WASHER (#17252750) |
| 62 | 92701120 | NUT (#92701120) |
| 63 | 90271038 | SNAP RING (90271038 ) USE 90271008 (#90271038) |
| 64 | 18257750 | 18257751 (#18257750) |
| 65 | 18257550 | COUPLER (#18257550) |
| 66 | 92700073 | NUT (#92700073) |
| 67 | 18250850 | TRANSMISSION CONTROL (#18250850) |
| 68 | 18252050 | BUSH NLA (#18252050) USE 30678160 |
| 69 | 13432640 | CENTER STAND/SIDE STAND RUBBER (#13432640) |
| 70 | 98054416 | BOLT (#98054416) |
| 71 | 95021108 | WASHER (#95021108) |
| 72 | 18259150 | WASHER (#18259150) USE 18259151 |
| 73 | 95129260 | SPRING WASHER (#95129260) |
| 74 | 18328250 | RUBBER SPACER (#18328250) |
| 75 | 18328150 | RING (#18328150) |
| 76 | 17093050 | CLUTCH CABLE CONVERT,G5,T3 (#17093050) |
| 77 | 17093850 | CABLE BOOT (#17093850) |
