1976 1981 1000 Convert Connecting And Timing System
| Position | Part Number | Description |
|---|---|---|
| 1 | 18064251 | CRANKSHAFT (#18064251) |
| 2 | 12065400 | CRANK PLUG (#12065400) |
| 3 | 91702355 | WOODRUFF KEY (#91702355) |
| 4 | 14072001 | SPROCKET (#14072001) |
| 5 | 95028025 | WASHER (#95028025) |
| 6 | 93601026 | CRANK RING NUT (#93601026) |
| 7 | 18066950 | FLYWHEEL USE 18067052 (#18066950) |
| 8 | 12067600 | TAB (#12067600) USE 14615901 |
| 9 | 12067701 | SCREW (#12067701) use 597150 |
| 10 | 18067950 | GEAR RING (#18067950) |
| 11 | 95187008 | LOCK PLATE (#95187008) USE 1461 5901 |
| 12 | 98054418 | BOLT (#98054418) |
| 13 | 14061501 | CON ROD (#14061501) |
| 14 | 91112122 | #14 Bushing (#91112122) |
| 15 | 92731090 | NUT (#92731090) |
| 16 | 14062201 | CONN.ROD BOLT USE 30062260 (#14062201) |
| 17 | 12062000 | HALF BEARING Use 01062030 (#12062000) |
| 17 | 12062001 | HALF BEARING USE 30062001 (#12062001) |
| 17 | 12062002 | ROD BEARING 1/2 (#12062002) |
| 17 | 12062003 | BEARING (#12062003) |
| 18 | 18060450 | PISTON (#18060450) |
| 19 | 18060750 | PISTON RING (#18060750) |
| 20 | 18060950 | PISTON RING (#18060950) |
| 21 | 18061050 | PISTON RING (#18061050) |
| 22 | 13061260 | PISTON PIN (#13061260) |
| 23 | 90351037 | CIRCLIP USE 27061385 (#90351037) |
| 24 | 18060250 | PISTON (#18060250) |
| 25 | 18060650 | RING SET (#18060650) USE 17060660 |
| 26 | 17045051 | 17045050 (#17045051) |
| 27 | 10045800 | 10045800 supercedes to 17045860 (#10045800) |
| 27 | 10045801 | TAPPET OR PLUNGER (#10045801) |
| 27 | 10045802 | VALVE PLUNGER (#10045802) |
| 28 | 18053351 | CAMSHAFT (#18053351) |
| 29 | 12054000 | FLANGE (#12054000) |
| 30 | 98054320 | BOLT (#98054320) |
| 31 | 95120065 | WASHER (#95120065) |
| 32 | 13054502 | GEAR (#13054502) |
| 33 | 95512060 | PIN ROLLER (#95512060) |
| 34 | 14433400 | WASHER (#14433400) |
| 35 | 92602518 | NUT (#92602518) |
| 36 | 13058000 | TIMING CHAIN (#13058000) |
| 37 | 13058200 | TENSIONER 30057810 (#13058200) |
| 38 | 91180915 | BUSHING (#91180915) |
| 39 | 98054440 | BOLT (#98054440) |
| 40 | 13058600 | (#13058600) USE 61270300 |
| 41 | 18245050 | CONVERTER (#18245050) |
