1976 1981 1000 Convert Front And Rear Suspensions
| Position | Part Number | Description |
|---|---|---|
| 1 | 18490250 | 51-FRT. FORK (#18490250) |
| 2 | 14504502 | PLUG (#14504502) |
| 3 | 90706238 | O RING (#90706238) |
| 4 | 17516600 | BUSHING 1451 6600 (#17516600) |
| 5 | 17517700 | DISC 1415 6600 (#17517700) |
| 6 | 98620435 | SCREW USE 9868 0435 (#98620435) |
| 7 | 95004208 | WASHER (#95004208) |
| 8 | 18500750 | SCREW (#18500750) |
| 9 | 17500200 | CLAMP (#17500200) |
| 10 | 17493100 | UPPER PLATE (#17493100) |
| 11 | 98622535 | SCREW (#98622535) |
| 12 | 95100837 | WASHER (#95100837) |
| 13 | 10513401 | NUT (#10513401) |
| 14 | 14494600 | CUP (#14494600) |
| 15 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 16 | 14516700 | SHIM (#14516700) |
| 17 | 14517000 | RING DUST SEAL (#14517000) |
| 18 | 17494000 | (#17494000) USE 17494001 |
| 19 | ||
| 20 | 17496100 | HL BRACKET RH {62496200} (#17496100) |
| 21 | 17496200 | HL BRACKET LH USE 62496100 (#17496200) |
| 22 | 14526407 | DAMPER (#14526407) |
| 23 | 92630106 | NUT USE 92630707 (#92630106) |
| 24 | 14526505 | RUBBER RING (#14526505) |
| 25 | 90271014 | RING USE 90271015 (#90271014) |
| 26 | 14527600 | NUT (#14527600) USE 18527950 |
| 27 | 14527800 | TUBE (#14527800) |
| 28 | 14527900 | CUP (#14527900) |
| 29 | 14526600 | SPRING EACH (#14526600) |
| 30 | 14525401 | FORK TUBE (#14525401) |
| 32 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 33 | 98622422 | SCREW (#98622422) |
| 34 | 17522520 | FORK LEG RH (#17522520) |
| 35 | 17522620 | FORK LEG LH (#17522620) |
| 36 | 98620540 | SCREW (#98620540) |
| 37 | 92602210 | NUT (#92602210) |
| 38 | 98620312 | OIL DRAIN PLUG ALLEN BOLT (#98620312) |
| 39 | 95100116 | WASHER (#95100116) |
| 40 | 90403547 | FORK SEAL- (#90403547) USE 90403449 |
| 41 | 14524500 | FORK DUST COVERS (#14524500) |
| 42 | 13550241 | SHOCKS USE 18550261 (#13550241) |
| 43 | 14552301 | SPRING (#14552301) |
| 44 | 95004215 | WASHER (#95004215) |
| 45 | 95100337 | WASHER (#95100337) |
| 47 | 98054416 | BOLT (#98054416) |
| 48 | 14530201 | STEERING DAMPER (#14530201) |
| 49 | 14530800 | SPACER 7 X 14 X 18 (#14530800) |
| 50 | 95100142 | WASHER (#95100142) |
| 51 | 98052335 | BOLT (#98052335) |
| 52 | 95000206 | WASHER (#95000206) |
