1976 1981 1000 Convert Gearbox And Cover
| Position | Part Number | Description |
|---|---|---|
| 1 | 18200550 | CONVERTER HOUSING (#18200550) |
| 2 | 95950470 | OIL CONNECTOR (#95950470) |
| 3 | 18161150 | GASKET (#18161150) |
| 4 | 95950360 | OIL RETURN CONNECTOR (#95950360) |
| 5 | 12006400 | ALUM CRUSH WASHER (#12006400) |
| 6 | 90404563 | SEAL RING (#90404563) |
| 7 | 98052440 | BOLT (#98052440) |
| 8 | 98052435 | BOLT (#98052435) |
| 9 | 95004208 | WASHER (#95004208) |
| 10 | 93180220 | TIMING HOLE PLUG (#93180220) |
| 11 | 12018900 | BUSH (#12018900) |
| 12 | 14115400 | WIRE GUIDE (#14115400) USE 14115401 |
| 13 | 91551081 | GROMMET (#91551081) |
| 14 | 18200250 | TRANS. CASE (#18200250) |
| 15 | 90402838 | SEAL (#90402838) |
| 16 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 17 | 14217900 | PLATE (#14217900) |
| 18 | 18213850 | FLANGE - PLATE (#18213850) |
| 19 | 92218421 | BEARING (#92218421) |
| 20 | 92201420 | BEARING (#92201420) |
| 21 | 18206550 | VENT PLUG (#18206550) |
| 22 | 12003702 | DRAIN PLUG MAGNETIC (#12003702) |
| 23 | 95100709 | CRUSH WASHER (95100709) (#95100709) |
| 24 | 98622314 | ALLEN BOLT (#98622314) |
| 25 | 95021106 | WASHER, WAVE (#95021106) |
| 26 | 95512081 | PIN (#95512081) |
| 27 | 18200850 | COVER (#18200850) |
| 28 | 18200350 | GASKET (#18200350) |
| 29 | 90401630 | SEAL RING (#90401630) |
| 30 | 90403547 | FORK SEAL- (#90403547) USE 90403449 |
| 31 | 92256218 | BEARING (#92256218) |
| 32 | 92201425 | BEARING (#92201425) |
| 33 | 98620325 | ALLEN BOLT (#98620325) |
| 34 | 93301175 | CABLE CLAMP (#93301175) |
| 35 | 95980610 | PLUG (#95980610) |
| 36 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 37 | 94321064 | SPRING (#94321064) |
| 38 | 18234750 | PAWL (#18234750) |
