1977 1980 V 35 V 50 Acc. Elettronica 350 500 Front Rear Brake System
| Position | Part Number | Description |
|---|---|---|
| 1 | 31666990 | MASTER CYL ASSY (#31666990) |
| 2 | 17659350 | Rear Master Cylinder Kit (Front for T) (#17659350) |
| 3 | 19659600 | PIN KIT (#19659600) |
| 4 | 19659500 | REV KIT (#19659500) |
| 5 | 19667500 | LEVER (#19667500) |
| 6 | 19667600 | SPRING (#19667600) |
| 7 | 95004206 | WASHER (#95004206) |
| 8 | 98052326 | BOLT (#98052326) |
| 9 | 61013800 | SPRING WASHER (#61013800) |
| 10 | 95021106 | WASHER, WAVE (#95021106) |
| 11 | 92602206 | NUT (#92602206) USE STHN6MM |
| 12 | 19668000 | SPLITTER (#19668000) |
| 13 | 95990028 | SCREW (#95990028) |
| 14 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 15 | ||
| 16 | 14657050 | SWITCH (BRAKE) (#14657050) |
| 17 | 23653011 | Rear brake caliper (#23653011) |
| 18 | 39659000 | CALIPER REVISION KIT (#39659000) |
| 18 | 66659031 | Brake caliper rev. kit GRIMECA (#66659031) |
| 19 | 31659165 | Pins+spring GRIMECA (#31659165) |
| 19 | 39659100 | REV KIT (#39659100) |
| 20 | 14659200 | BLEEDER SCREW KIT (1 PR) (#14659200) |
| 20 | 31659265 | Bleeder+cap GRIMECA (#31659265) |
| 21 | 27654610 | PAD SET (#27654610) |
| 21 | 31654665 | Pads pair GRIMECA (#31654665) |
| 22 | 31654765 | Brake caliper cover GRIMECA (#31654765) |
| 22 | 39654700 | COVER (#39654700) |
| 23 | 98622422 | SCREW (#98622422) |
| 24 | 61270300 | WASHER (#61270300) |
| 25 | 95100250 | SHIM (#95100250) |
| 25 | 95100251 | WASHER (#95100251) |
| 26 | 19658700 | PIPE (#19658700) |
| 27 | 17659650 | TUBE (#17659650) |
| 28 | 62436500 | BRACKET (#62436500) |
| 29 | 90716142 | SLEEVE (#90716142) |
| 30 | 14609650 | TIE WRAP (#14609650) |
| 31 | ||
| 32 | 31652365 | LH front brake caliper Grimeca (#31652365) |
| 33 | 19677000 | PEDAL (#19677000) |
| 34 | 14251001 | SHIFT AND BRAKE PEDAL RUBBER (#14251001) |
| 35 | 95129260 | SPRING WASHER (#95129260) |
| 36 | 95004215 | WASHER (#95004215) |
| 37 | 95500227 | COTTER PIN (#95500227) |
| 38 | 19675000 | ROD CONNECTION (#19675000) |
| 40 | 92700073 | NUT (#92700073) |
| 41 | 18257551 | BLOCK (#18257551) |
| 42 | 90271008 | SNAP RING (#90271008) |
| 43 | 95770265 | PIN (#95770265) |
| 44 | 95129110 | WASHER (#95129110) |
| 45 | 95500222 | SPLIT PIN (#95500222) |
| 47 | 17659352 | Front Master Cylinder Kit (#17659352) |
| 48 | 19663300 | LEVER (#19663300) |
| 49 | 19662600 | SPRING (#19662600) |
| 50 | 98052325 | BOLT (#98052325) |
| 51 | 19657100 | HOSE (#19657100) |
| 52 | 31652265 | RH front brake caliper Grimeca (#31652265) |
| 53 | 19665000 | TANK FOR MASTER CYL. (#19665000) |
| 54 | 14661100 | CAP (#14661100) |
| 55 | 14661300 | BELLOWS M/C REAR WAS 17661350 (#14661300) |
| 56 | 00823950050 | TUBE (#00823950050) |
| 57 | 61108500 | CLIP (#61108500) |
| 58 | 00823947120 | pipe (#00823947120) |
| 59 | 12735100 | CAP (#12735100) |
