1979 1983 Sp 1000 Foot Rests Lateral Stand
| Position | Part Number | Description |
|---|---|---|
| 1 | 95021108 | WASHER (#95021108) |
| 2 | 92602208 | NUT (#92602208) |
| 3 | 17432060 | ARM (#17432060) |
| 4 | 95004208 | WASHER (#95004208) |
| 5 | 99105129 | BOLT (#99105129) |
| 6 | 17434060 | SPRING (#17434060) |
| 7 | 14418200 | BATTERY PLATE (#14418200) |
| 8 | 98054416 | BOLT (#98054416) |
| 9 | 174303621 | Central stand (#174303621) |
| 10 | 14433200 | PLATE USE 0343 3270 LH (#14433200) |
| 11 | 14432900 | PLATE USE 03432970 RH (#14432900) |
| 12 | 12434001 | SPRING (#12434001) |
| 13 | 14433500 | BUSHING (#14433500) |
| 14 | 98052545 | SCREW (#98052545) |
| 15 | 95004210 | WASHER (#95004210) |
| 16 | 14433400 | WASHER (#14433400) |
| 17 | 92630108 | NUT 8MM (#92630108) |
| 18 | 92630110 | NUT (#92630110) |
| 19 | 17420350 | ARM (#17420350) |
| 20 | 174221501 | LH craddle arm (#174221501) |
| 21 | 14423800 | RUBBER (#14423800) |
| 22 | 17443660 | RH FOOTREST (#17443660) |
| 23 | 17446050 | LEFT HAND FOOT REST (17446050) (#17446050) |
| 24 | 17444250 | SPACER (#17444250) |
| 25 | 14443200 | FOOT PEG RUBBER (#14443200) |
| 26 | 92601206 | NUT (#92601206) |
| 27 | 98052325 | BOLT (#98052325) |
| 28 | 144413501 | Footrest (#144413501) |
| 29 | 17432761 | PLATE (#17432761) |
| 30 | 98613635 | screw (#98613635) |
| 31 | 13432640 | CENTER STAND/SIDE STAND RUBBER (#13432640) |
| 32 | 92602512 | NUT (#92602512) |
| 33 | 92602312 | NUT (#92602312) |
| 34 | 95022112 | Washer (#95022112) |
| 35 | 14429505 | BOLT (#14429505) |
| 36 | 03429600 | Rear Bolt (#03429600) |
| 37 | 14429900 | SPACER (#14429900) |
| 38 | 14429800 | SPACER (#14429800) |
| 39 | 95000213 | WASHER (#95000213) |
| 40 | 98613630 | SCREW (#98613630) |
