1982 1985 V 65 Custom 650 Body
| Position | Part Number | Description |
|---|---|---|
| 1 | ||
| 1 | 23100282 | #01 Fuel tank (#23100282) |
| 1 | 23100283 | #01 Fuel tank (#23100283) |
| 1 | 23100284 | BLACK TANK (#23100284) |
| 1 | ||
| 2 | 23923380 | DECALS (#23923380) |
| 2 | 23923381 | DECALS (#23923381) |
| 2 | 23923382 | DECALS (#23923382) |
| 3 | 65105400 | RH PETCOCK RH (#65105400) |
| 4 | 65105401 | PETCOCK LH (#65105401) |
| 5 | 19102750 | STRAP (#19102750) |
| 6 | 23434280 | FRONT FENDER (#23434280) |
| 7 | 27436920 | #02 Splash guard (#27436920) |
| 9 | 92602208 | NUT (#92602208) |
| 10 | 61270300 | WASHER (#61270300) |
| 11 | 30103960 | GAS CAP (#30103960) |
| 12 | 23461680 | BUFFER (#23461680) |
| 13 | 14917300 | BADGE (#14917300) |
| 14 | 14105100 | HOLDER OR CLIP (#14105100) |
| 15 | 23460580 | SEAT V65C (#23460580) |
| 15 | 23460581 | SEAT V65C (#23460581) |
| 16 | 23464380 | HAND GRIP (#23464380) |
| 16 | 23466580 | REAR CARRIER A (#23466580) |
| 17 | 98822420 | SCREW (#98822420) |
| 18 | 95000208 | WASHER (#95000208) |
| 20 | 92630508 | NUT (#92630508) |
| 21 | 23468780 | SADDLE LOCK (#23468780) |
| 22 | 23462980 | PIN (#23462980) |
| 23 | 19478550 | RUBBER GROMMET LOWER FOR SIDE COVER V35-V50 (#19478550) |
| 24 | 91551085 | RUBBER BLOCK USE 9155 1086 (#91551085) |
| 25 | 23437080 | RR FENDER CHR (#23437080) |
| 26 | 23438980 | GASKET (#23438980) |
| 27 | 91551102 | GROMMET (#91551102) |
| 28 | 98054320 | BOLT (#98054320) |
| 29 | 95000206 | WASHER (#95000206) |
| 30 | 92602206 | NUT (#92602206) USE STHN6MM |
| 31 | 23438780 | HOUSING (#23438780) |
| 32 | 23476580 | R ELEMENT (#23476580) |
| 33 | 23477280 | LH CHROME ***NLA*** (#23477280) |
| 34 | 93110060 | RUBBER WASHER (#93110060) |
| 35 | 95100141 | WASHER (#95100141) |
| 36 | 92630106 | NUT USE 92630707 (#92630106) |
| 37 | 23476061 | RH COVER RED USE 2347 6080/1 (#23476061) |
| 37 | 23476062 | #37 RH side panel (#23476062) |
| 37 | 23476063 | #37 RH side panel (#23476063) |
| 37 | 23476064 | RH COVER BLK USE 2347 6080/1 (#23476064) |
| 37 | 23476065 | RH COVER WHITE USE 2347 6080/1 (#23476065) |
| 38 | 23476161 | LH COVER RED USE 2347 6180/1 (#23476161) |
| 38 | 23476162 | #38 LH side panel (#23476162) |
| 38 | 23476163 | #38 LH side panel (#23476163) |
| 38 | 23476164 | LH COVER BLK USE 2347 6180/1 (#23476164) |
| 38 | 23476165 | LH COVER WHITE 2347 6180/1 (#23476165) |
| 39 | 23922060 | R MARK V65C (#23922060) |
| 40 | 62100600 | CAP (#62100600) |
| 42 | 19705900 | PLUG (#19705900) |
