1982 1990 V 50 Pol. pa Vechiotipo 500 Clutch
| Position | Part Number | Description |
|---|---|---|
| 1 | 19084100 | SPRING-PLATE (#19084100) |
| 2 | 19082501 | PR. PLATE ASSY. (#19082501) |
| 3 | 98054214 | BOLT (#98054214) |
| 4 | 95004205 | WASHER (#95004205) |
| 5 | 92630105 | NUT (#92630105) |
| 7 | 27084420 | CLUTCH PLATE V50 (#27084420) |
| 8 | 20085720 | CLUTCH ROD (#20085720) |
| 9 | 14086000 | INNER CLUTCH BODY (#14086000) |
| 10 | 12087001 | THROWOUT BEARING 5 SPEED (12087001) |
| 11 | 14086100 | OUTER CLUTCH BODY (#14086100) |
| 12 | 90706170 | O RING (#90706170) |
| 13 | 14090201 | LEVER (#14090201) |
| 14 | 14090400 | SCREW (#14090400) |
| 15 | ||
| 16 | 94321105 | SPRING (#94321105) |
| 17 | 95780271 | PIN (#95780271) |
| 18 | 95500222 | SPLIT PIN (#95500222) |
| 19 | 90402841 | RING (#90402841) USE 886364 |
| 20 | 19210740 | INPUT SHAFT (#19210740) |
| 21 | 90400616 | SEAL (#90400616) |
| 22 | 19213720 | SPACER (#19213720) |
| 23 | 90706188 | O RING (#90706188) |
| 24 | 19356700 | NUT (#19356700) |
| 25 | 19080300 | CLUTCH HOUSING (#19080300) |
| 26 | 19200422 | Clutch drum (#19200422) |
| 27 | 93180220 | TIMING HOLE PLUG (#93180220) |
| 28 | 92201220 | BEARING (#92201220) |
| 29 | 19203420 | PLATE A (#19203420) |
| 30 | 98054314 | SCREW (#98054314) |
| 31 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 32 | 98620330 | V/COVER BOLT (#98620330) USE 98680330 |
| 33 | 98620435 | SCREW USE 9868 0435 (#98620435) |
| 35 | 19083462 | CL CUP (#19083462) |
| 36 | 19080161 | CL DEVICE (#19080161) |
| 37 | 90272075 | RING (#90272075) |
| 38 | 98620450 | ALLEN BOLT (#98620450) |
| 39 | 98620440 | SCREW (#98620440) |
