1982 1990 V 50 Pol. pa Vechiotipo 500 Front Foot Rests Lateral Stand
| Position | Part Number | Description |
|---|---|---|
| 1 | 98052565 | BOLT (#98052565) |
| 2 | 95004210 | WASHER (#95004210) |
| 3 | 92602210 | NUT (#92602210) |
| 4 | 18252050 | BUSH NLA (#18252050) USE 30678160 |
| 5 | 19420300 | RH ARM (#19420300) |
| 5 | 19420320 | RH ARM (#19420320) |
| 6 | 19422100 | LH ARM (#19422100) |
| 6 | 19422120 | ARM (#19422120) |
| 7 | 92602206 | NUT (#92602206) USE STHN6MM |
| 8 | 98054322 | BOLT (#98054322) |
| 9 | 19430305 | CENTER STAND (#19430305) |
| 10 | 13432640 | CENTER STAND/SIDE STAND RUBBER (#13432640) |
| 11 | 12434001 | SPRING (#12434001) |
| 12 | 98054530 | BOLT (#98054530) |
| 13 | 91181114 | SPACER (#91181114) |
| 14 | 94322215 | SPRING-ROCKER (#94322215) |
| 15 | 95000210 | WASHER (#95000210) |
| 16 | 92630510 | NUT (#92630510) |
| 17 | 19432000 | SIDE STAND (#19432000) |
| 18 | 19433000 | PLUG (#19433000) |
| 19 | 99105126 | #19 Pin (#99105126) |
| 20 | 19434000 | SPRING (#19434000) |
| 21 | 39440700 | SUPPORT (#39440700) |
| 22 | 39441800 | PIPE (#39441800) |
| 23 | 98820430 | ALLEN BOLT (#98820430) |
| 24 | 92602208 | NUT (#92602208) |
| 25 | 39443200 | FOOTPEG RUBBER (#39443200) |
| 26 | 53429500 | BOLT (#53429500) |
| 27 | 19017000 | BUSH (#19017000) |
