1982 1990 V 50 Pol. pa Vechiotipo 500 Magura Handlebar Controls
| Position | Part Number | Description |
|---|---|---|
| 2 | 30607910 | CABLE SPLITTER (#30607910) |
| 3 | 23117570 | Throttle cable (23117570) (#23117570) |
| 4 | 23117770 | Throttle cable (#23117770) |
| 5 | 19738015 | #05 LH lights selector (#19738015) |
| 6 | 19750315 | #06 RH lights selector (#19750315) |
| 7 | 98260425 | #04 Screw (#98260425) |
| 8 | 29999250 | Throttle cable (#29999250) |
| 10 | 29605550 | #06 Clutch lever (#29605550) |
| 11 | 29608750 | CABLE END (#29608750) |
| 13 | 29603650 | #14 Side cover (#29603650) |
| 14 | 98280410 | SCREW (#98280410) |
| 15 | 29603550 | GRIP (#29603550) |
| 16 | 29603050 | GRIP (#29603050) |
| 17 | 39741101 | STOP SWITCH (#39741101) |
| 18 | 29604650 | #12 Nylon washer (#29604650) |
| 19 | 29603750 | CABLE GUIDE (#29603750) |
| 20 | 29604850 | STUD (#29604850) |
| 21 | 92601206 | NUT (#92601206) |
| 22 | 98612316 | ALLEN BOLT (#98612316) |
| 23 | 29660250 | #01 Front master cylinder (#29660250) |
| 24 | 98812216 | #02 Screw (#98812216) |
| 25 | 23661110 | #13 Cover (#23661110) |
| 26 | 23659310 | #14 Brake mast.cyl rev. kit (#23659310 ) |
| 27 | 23093070 | Clutch Cable (23093070) (#23093070) |
| 28 | 23093870 | RUBBER BOOT (#23093870) |
| 29 | 19747195 | Electrical system (#19747195) |
| 30 | 19747295 | #30 Headlight wiring w/harness (#19747295) |
| 31 | 28999546 | RH rearview mirror (#28999546) |
| 33 | 23657110 | Front brake line (#23657110) |
| 34 | 17658360 | CLAMP (#17658360) |
| 35 | 17658260 | RUBBER RING (#17658260) |
| 37 | 92630104 | NUT (#92630104) |
