1984 1987 V 65 Lario Carburetor

Position Part Number Description
1 27112660 CARB RH EUR B (#27112660)
2 27112661 CARB LH EUR B (#27112661)
3 19115060 RH SLEEVE (#19115060)
4 19115061 LH SLEEVE (#19115061)
5 19115580 INTAKE GASKET (#19115580)
6 98310610 SCREW (#98310610)
7 95100116 WASHER (#95100116)
8 98822325 SCREW (#98822325)
9 61013800 SPRING WASHER (#61013800)
10 19114360 INTAKE SLEEVE USE 31114383 (#19114360)
11 93305045 CLAMP (#93305045) USE 93305032
12 19114680 RING (#19114680)
13 19114460 AIR INTAKE (#19114460)
14 27133160 STARTER DEVICE 23133100 (#27133160)
15 19133560 CABLE (#19133560)
16 19134000 CABLE (#19134000)
17 19718000 CLAMP (#19718000)
