1984 1987 V 65 Lario Front And Rear Mudguard
| Position | Part Number | Description |
|---|---|---|
| 1 | 27434421 | USE 27434321 (#27434421) |
| 1 | 27434422 | FRT FNDER-WHITE A (#27434422) |
| 1 | 27434423 | FRT FNDER-GRAY A (#27434423) |
| 2 | 982300616 | Screw (#982300616) |
| 3 | 19438735 | PROTECTION (#19438735) |
| 4 | 98054325 | BOLT (#98054325) |
| 5 | 93110060 | RUBBER WASHER (#93110060) |
| 6 | 95000206 | WASHER (#95000206) |
| 7 | 95100141 | WASHER (#95100141) |
| 8 | 92630106 | NUT USE 92630707 (#92630106) |
| 10 | 27437020 | USE 31437015 (#27437020) |
| 11 | 98054314 | SCREW (#98054314) |
| 12 | 95004206 | WASHER (#95004206) |
| 13 | 95100118 | WASHER (#95100118) |
| 15 | 27439120 | FENDER SUPPORT (#27439120) |
| 16 | 98822418 | SCREW (#98822418) |
| 17 | 95004208 | WASHER (#95004208) |
| 18 | 92602208 | NUT (#92602208) |
| 19 | 39474600 | NUMBER PLATE HOLDER (#39474600) |
| 20 | 98200408 | SCREW (#98200408) |
| 21 | 95000204 | WASHER (#95000204) |
| 22 | 95129080 | WASHER (#95129080) |
| 23 | 92602204 | NUT (#92602204) |
| 24 | 28659740 | GROMMET (#28659740) |
