1989 1994 S 1000 Carburetors
| Position | Part Number | Description |
|---|---|---|
| 1 | 28937560 | ROUND SLIDE 6/50 (#28937560) |
| 2 | 28937760 | SLIDE NEEDLE K19 (#28937760) |
| 3 | 28935590 | ATOMIZER #AB266 (#28935590) |
| 4 | 28935760 | (#28935760) USE 6413+ MJ NUMBER |
| 5 | 28935960 | #57 MAIN JET (#28935960) use 148657 |
| 6 | 19936000 | STARTER JET #60 (#19936000) |
| 7 | 28939060 | PUMP JET #35 (#28939060) |
| 8 | 14939150 | NEEDLE VALVE (#14939150) |
| 9 | 14933000 | FLOATS - ALL BIG BLOCK (#14933000) |
| 11 | 13932900 | WASHER (#13932900) |
| 13 | 14933550 | LEVER (#14933550) |
| 16 | 14938050 | SPRING (#14938050) |
| 17 | 14938150 | LEVER ACCEL PUMP 30,32,34MM (#14938150) |
| 18 | 14933450 | SCREW (#14933450) |
| 19 | 14933650 | WASHER A (#14933650) |
| 20 | 14933150 | COVER (#14933150) |
| 22 | 14934650 | SCREW (#14934650) |
| 25 | 14935450 | COVER (#14935450) |
| 40 | 14934850 | LOCK WASHER (#14934850) |
| 41 | 14934950 | SCREW (#14934950) |
| 43 | 14931650 | WASHER A (#14931650) |
| 44 | 13936700 | SPRING (#13936700) |
| 45 | 13936600 | SCREW (#13936600) |
| 47 | 65933700 | WASHER (#65933700) |
| 48 | 13936300 | SPRING (#13936300) |
| 49 | 13936200 | SCREW (#13936200) |
| 51 | 12937200 | CABLE ADJUSTER (#12937200) |
| 52 | 12937300 | NUT (#12937300) |
| 56 | 39937600 | SPRING (#39937600) |
| 57 | 13937800 | VALVE CHOKE (#13937800) |
| 66 | 14936550 | SCREW (#14936550) |
| 67 | 14936450 | NUT (#14936450) |
| 69 | 14936850 | COVER (#14936850) |
| 70 | 14936950 | SPRING (#14936950) |
| 71 | 14931050 | DIAPHRAGM (#14931050) |
| 73 | 14931350 | VALVE (#14931350) |
| 75 | 43934000 | Fuel Filter Screen (43934000) (#43934000) |
| 77 | 10934900 | BOLT (#10934900) |
| 80 | 13933100 | FLOAT PIN (13933100) (#13933100) |
| 89 | 28939960 | CARB GASKET KIT (#28939960) |
