1989 1994 S 1000 Frame
| Position | Part Number | Description |
|---|---|---|
| 1 | 14400170 | #01 Frame (#14400170) |
| 2 | 19782520 | LOCK CYLINDER (#19782520) |
| 3 | 14103800 | BUSH (#14103800) |
| 4 | 14109000 | BUSHING (#14109000) |
| 5 | 35782780 | SEAT LOCK (#35782780) |
| 6 | 98074425 | BOLT BLACK (#98074425) |
| 7 | 98054320 | BOLT (#98054320) |
| 8 | 95100121 | WASHER (#95100121) |
| 9 | 95001208 | WASHER (#95001208) |
| 10 | 92630106 | NUT USE 92630707 (#92630106) |
| 11 | 91180810 | SPACER (#91180810) |
| 12 | 14103400 | TANK BUSHING (#14103400) |
| 13 | 14107100 | RUBBER BUSHING (#14107100) |
| 14 | 98621670 | SCREW (#98621670) |
| 15 | 95021112 | WASHER (#95021112) |
| 16 | 92602312 | NUT (#92602312) |
| 17 | 14429500 | BOLT (ROD) (#14429500) |
| 18 | 95001213 | WASHER A (#95001213) |
| 19 | 92601312 | NUT A (#92601312) |
| 20 | 14609650 | TIE WRAP (#14609650) |
| 21 | 14418200 | BATTERY PLATE (#14418200) |
| 22 | 98054416 | BOLT (#98054416) |
| 23 | 95004208 | WASHER (#95004208) |
| 24 | 95021108 | WASHER (#95021108) |
| 25 | 92602208 | NUT (#92602208) |
| 26 | 14462770 | #26 RH helmet holder (#14462770) |
| 27 | 14462870 | #27 LH helmet holder (#14462870) |
| 28 | ||
| 29 | 14479670 | TOOL TRAY A (#14479670) |
| 30 | 28478550 | STUD (#28478550) |
| 31 | 91180604 | SPACER (#91180604) |
| 32 | 98054318 | BOLT (#98054318) |
| 33 | 61013800 | SPRING WASHER (#61013800) |
| 34 | 30716710 | PLATE A (#30716710) |
| 35 | 29716650 | BUFFER (#29716650) |
| 36 | 35782880 | SCREW (#35782880) |
| 37 | 19705900 | PLUG (#19705900) |
| 38 | 29579460 | GASKET (#29579460) |
