1990 1992 Sp 750 Battery
| Position | Part Number | Description |
|---|---|---|
| 2 | ||
| 3 | 27705520 | STRAP (#27705520) |
| 4 | 27704820 | 27704820 Battery fixing support (#27704820) |
| 5 | 14717600 | SPARK PLUG RUBBER BOOT (#14717600) |
| 6 | ||
| 7 | 31716560 | COIL LARIO (#31716560) |
| 8 | 98620240 | ALLEN BOLT (#98620240) |
| 9 | 91180721 | BUSHING (#91180721) |
| 10 | 31717015 | #11 Spark plug CHAMPION N3C (#31717015) |
| 10 | 31717060 | SPARK PLUG A (#31717060) |
| 12 | 23707100 | CABLE BOOT (#23707100) |
| 13 | 19748400 | CABLE (#19748400) |
| 14 | 28712459 | SCREW (SAPRISA) (#28712459) |
| 15 | 95129100 | WASHER (#95129100) |
| 16 | 92660501 | CAGE NUT (#92660501) |
| 17 | ||
| 18 | 28703800 | REG (SAPRISA) (#28703800) |
| 19 | 95100059 | WASHER (#95100059) |
| 20 | 14609650 | TIE WRAP (#14609650) |
| 21 | 98202516 | SCREWS (#98202516) |
| 22 | 19707100 | CAP (#19707100) |
| 23 | 19748000 | CABLE (#19748000) |
| 24 | 98325012 | SCREW (#98325012) |
| 25 | 95000205 | WASHER (#95000205) |
| 26 | 29722270 | ELECTRONIC IGNITION PICKUP (#29722270) |
| 27 | 98622318 | SCREW (#98622318) |
| 28 | 98620250 | SCREW (#98620250) |
| 29 | 27721063 | #04 Rotor (#27721063) |
| 30 | 95021105 | LOCK WASHER (#95021105) |
