1992 1997 Quota 1000 Electrical System
| Position | Part Number | Description |
|---|---|---|
| 1 | 30747130 | Main wiring harness (#30747130) |
| 2 | 30747230 | Dashboard cable (#30747230) |
| 3 | 30747430 | Headlight wiring w/harness (#30747430) |
| 4 | 30743000 | FUSE BOX ASSY A (#30743000) |
| 5 | 28742560 | FUSE 15A (#28742560) use 290860 |
| 6 | 98202516 | SCREWS (#98202516) |
| 7 | 95100059 | WASHER (#95100059) |
| 8 | 92660501 | CAGE NUT (#92660501) |
| 9 | 30945000 | DECAL FUSEBOX A (#30945000) |
| 10 | 30732510 | RELAY (#30732510) |
| 11 | 17750520 | TURN SIGNAL FLASHER (#17750520) |
| 12 | 14609650 | TIE WRAP (#14609650) |
| 13 | 30748430 | BATTERY CABLE (#30748430) |
| 14 | 19748000 | CABLE (#19748000) |
| 15 | 30747930 | #10 Engine-frame ground wiring (#30747930) |
| 16 | 30724630 | Front b.l. switch wiring (#30724630) |
| 17 | 30704500 | BATTERY B (#30704500) |
| 17 | 31704560 | #01 Battery Y50-N18L-A (#31704560) |
| 18 | 30704830 | BATTERY STRAP (#30704830) |
| 19 | 30707030 | BATTERY PAD (#30707030) |
| 20 | 14705350 | BATTERY WEDGE (#14705350) |
| 21 | 19705900 | PLUG (#19705900) |
| 22 | 28749778 | #29 Plate (#28749778) |
| 23 | 92660601 | CAGE NUT (#92660601) |
| 24 | 98326014 | SCREW (#98326014) |
| 25 | 00823946060 | Breather pipe (#00823946060) |
| 26 | 30472630 | Maintenance (#30472630) |
| 27 | 98230616 | SCREW (#98230616) |
| 28 | 91551085 | RUBBER BLOCK USE 9155 1086 (#91551085) |
| 29 | 91180607 | SPACER (#91180607) |
| 31 | 93304390 | TIE WRAP (#93304390) |
| 32 | 19707100 | CAP (#19707100) |
