1992 1997 Quota 1000 Fairing
| Position | Part Number | Description |
|---|---|---|
| 1 | 305754301 | Windshield (#305754301) |
| 1 | 30575431 | Windshield (#30575431) |
| 1 | 30575432 | Windshield (#30575432) |
| 1 | 30575433 | Windshield (#30575433) |
| 1 | 89000054 | Windshield (#89000054) |
| 2 | 30577230 | WINDSCREEN (#30577230) |
| 3 | 23922210 | FASTENER (#23922210) |
| 4 | ||
| 5 | 93222020 | RUBBER MOUNT (#93222020) USE 93222023 |
| 6 | 95000206 | WASHER (#95000206) |
| 7 | 92630106 | NUT USE 92630707 (#92630106) |
| 8 | 98230622 | ALLEN SCREW (#98230622) |
| 9 | 29577860 | PLASTIC WASHER (#29577860) |
| 10 | 98230515 | ALLEN SCREW (#98230515) USE 98370515 |
| 10 | 98230619 | SCREW (#98230619) |
| 11 | 30577800 | NYLON WASHER (#30577800) |
| 12 | 93231605 | FASTENER (#93231605) |
| 12 | 93231606 | RUBBER BUSHING (#93231606) |
| 13 | 92630206 | NUT (#92630206) |
| 14 | ||
| 15 | 91180608 | SPACER (#91180608) |
| 16 | 305759301 | #16 Grille, blank (#305759301) |
| 16 | 30575931 | Grid (#30575931) |
| 16 | 30575932 | Grid (#30575932) |
| 16 | 30575933 | Grid (#30575933) |
| 16 | 89000057 | Grid (#89000057) |
| 17 | 30575830 | RH SCREEN (#30575830) |
| 18 | 30575831 | LH SCREEN (#30575831) |
| 19 | 305703301 | RH FRONT FAIRING, BLANK (#305703301) |
| 19 | 30570331 | RH front fairing (#30570331) |
| 19 | 30570332 | RH front fairing (#30570332) |
| 19 | 30570333 | RH front fairing (#30570333) |
| 19 | 89000055 | RH front fairing (#89000055) |
| 20 | 305704301 | SIDE (#305704301) |
| 20 | 30570431 | LH front fairing (#30570431) |
| 20 | 30570432 | LH front fairing (#30570432) |
| 20 | 30570433 | LH front fairing (#30570433) |
| 20 | 89000056 | LH front fairing (#89000056) |
| 21 | 304664301 | TAIL (#304664301) |
| 21 | 30466431 | Rear fairing (#30466431) |
| 21 | 30466432 | Rear fairing (#30466432) |
| 21 | 30466433 | Rear fairing (#30466433) |
| 21 | 89000061 | Rear fairing (#89000061) |
| 22 | 304762301 | RH side panel (#304762301) |
| 22 | 30476231 | RH side panel (#30476231) |
| 22 | 30476232 | RH side panel (#30476232) |
| 22 | 30476233 | RH side panel (#30476233) |
| 22 | 89000059 | RH side panel (#89000059) |
| 23 | 304763301 | LH side panel (#304763301) |
| 23 | 30476331 | LH side panel (#30476331) |
| 23 | 30476332 | LH side panel (#30476332) |
| 23 | 30476333 | LH side panel (#30476333) |
| 23 | 89000060 | LH side panel (#89000060) |
| 24 | 97250617 | PIN (#97250617) |
| 26 | 28576590 | CLIP A (#28576590) |
| 27 | 98230616 | SCREW (#98230616) |
| 28 | 30923330 | Decal set (#30923330) |
| 29 | 99210311 | Self-Tap Screw (#99210311) |
| 30 | 30917830 | Decal Moto Guzzi (#30917830) |
| 31 | 30923530 | Decal Quota (#30923530) |
| 32 | 30922530 | Decal Fuel Injection (#30922530) |
| 33 | 30922130 | Decal 1000 inch (#30922130) |
