1992 1997 Quota 1000 Throttle Body
| Position | Part Number | Description |
|---|---|---|
| 1 | 30112630 | THROTTLE BODY ASSY (#30112630) |
| 2 | 30113930 | THROTTLE BODY GASKET (#30113930) |
| 3 | 30115730 | FUEL INJECTOR B (#30115730) |
| 4 | 98610245 | SCREW (#98610245) |
| 5 | 95129100 | WASHER (#95129100) |
| 6 | 98622430 | SCREW (#98622430) |
| 7 | 14615901 | WASHER (#14615901) |
| 8 | 30114430 | AIRBOX CONN. TUBE (#30114430) |
| 9 | 93305093 | CLAMP (#93305093) |
| 10 | 90706409 | OIL PUMP SEAL (#90706409) |
| 11 | 30115030 | RH intake manifold (#30115030) |
| 11 | 30115032 | INTAKE MANIFOLD (#30115032) |
| 12 | 30115031 | LH intake manifold (#30115031) |
| 12 | 30115033 | INTAKE MANIFOLD (#30115033) |
| 13 | 98316010 | screw (#98316010) |
| 14 | 95100116 | WASHER (#95100116) |
| 15 | 98622325 | BOLT CHROME (#98622325) |
| 16 | 95004206 | WASHER (#95004206) |
| 17 | 12006500 | BAND (#12006500) |
| 18 | 30114330 | MANIFOLD CONNECTING HOSE (#30114330) |
| 19 | 12548401 | CLAMP (#12548401) USE 93306050 |
| 20 | 30116930 | Maintenance (#30116930) |
| 20 | 30116931 | INTAKE UNION (#30116931) |
| 21 | 93202208 | #17 Silent-block (#93202208) |
| 22 | 98622435 | ALLEN BOLT (#98622435) |
| 23 | 30425330 | SUPPORT (#30425330) |
| 24 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 25 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 26 | 30113730 | AIR BOX (#30113730) |
| 27 | 30113600 | AIR FILTER (#30113600) |
| 28 | 30113430 | AIR BOX COVER (#30113430) |
| 29 | 98620260 | SCREW (#98620260) |
| 30 | 95004205 | WASHER (#95004205) |
| 31 | 98620235 | ALLEN BOLT (#98620235) |
| 32 | 93222020 | RUBBER MOUNT (#93222020) USE 93222023 |
| 33 | 98622320 | SCREW (#98622320) |
| 34 | 30112930 | LINKAGE COVER (#30112930) |
| 35 | 98200408 | SCREW (#98200408) |
| 36 | 30530553 | Throttle Body Sensor (#30530553) |
