1992 2001 V 35 Carabinieri pa 350 Battery Motoplat Ignition
| Position | Part Number | Description |
|---|---|---|
| 1 | 03704540 | BATTERY B (#03704540) |
| 1 | 14704505 | BATTERY COVER (#14704505) |
| 2 | 14707000 | BATTERY TRAY (#14707000) |
| 3 | 95004205 | WASHER (#95004205) |
| 4 | 19704800 | BATTERY STRAP (#19704800) |
| 5 | 14717600 | SPARK PLUG RUBBER BOOT (#14717600) |
| 6 | ||
| 6 | 30717410 | PLUG CAP NGK (#30717410) USE AP8212219 |
| 7 | 31716560 | COIL LARIO (#31716560) |
| 8 | 98620240 | ALLEN BOLT (#98620240) |
| 9 | 91180721 | BUSHING (#91180721) |
| 10 | 31717060 | SPARK PLUG A (#31717060) |
| 11 | ||
| 12 | 14704205 | Cover (#14704205) |
| 13 | 19748400 | CABLE (#19748400) |
| 14 | 14712459 | SCREW ALTERNATOR BOLT (BOSCH) (#14712459) |
| 15 | 95021105 | LOCK WASHER (#95021105) |
| 16 | 92602205 | NUT (#92602205) |
| 17 | 17712400 | ALTERNATOR (#17712400) |
| 18 | 29703800 | REGULATOR (#29703800) USE 040003 |
| 19 | 95100060 | WASHER (#95100060) |
| 20 | 14609650 | TIE WRAP (#14609650) |
| 21 | 98052245 | BOLT (#98052245) |
| 22 | 19707100 | CAP (#19707100) |
| 23 | 19748000 | CABLE (#19748000) |
| 24 | 98290512 | SCREW A (#98290512) |
| 25 | 95000205 | WASHER (#95000205) |
| 26 | 29722270 | ELECTRONIC IGNITION PICKUP (#29722270) |
| 27 | 98622318 | SCREW (#98622318) |
| 28 | 98620245 | SCREW (#98620245) |
| 29 | 27721063 | #04 Rotor (#27721063) |
| 31 | 23707100 | CABLE BOOT (#23707100) |
| 32 | 29743602 | Support plate (#29743602) |
| 33 | 91180605 | SPACER (#91180605) |
| 34 | 95129100 | WASHER (#95129100) |
| 35 | 98054214 | BOLT (#98054214) |
| 36 | 91180627 | SPACER (#91180627) |
| 37 | ||
| 38 | 28703800 | REG (SAPRISA) (#28703800) |
| 39 | 28712500 | CONNECTOR (#28712500) |
| 41 | 98620250 | SCREW (#98620250) |
| 42 | 28712459 | SCREW (SAPRISA) (#28712459) |
