1992 2001 V 35 Carabinieri pa 350 Crank Case
| Position | Part Number | Description |
|---|---|---|
| 1 | 19000120 | CRANKCASE V35 V50 (#19000120) |
| 1 | 31000380 | #01 Crankcase, grey (#31000380) |
| 2 | 96451560 | STUD (#96451560) |
| 3 | 96451430 | BOLT (#96451430) |
| 4 | 96508055 | STUD (#96508055) |
| 5 | 19015020 | BUSH (#19015020) |
| 6 | 61270300 | WASHER (#61270300) |
| 7 | 92602208 | NUT (#92602208) |
| 8 | 19003800 | CONNECTION (#19003800) |
| 9 | 19002020 | BUSH (#19002020) |
| 10 | 19016320 | PLUG (#19016320) |
| 11 | 90401530 | RING (#90401530) |
| 13 | 04000500 | SEAL (#04000500) USE 886365 |
| 13 | 90405367 | CRANKSHAFT SEAL - REAR MAIN (#90405367) |
| 14 | 19001420 | Timing system cover, blank (#19001420) |
| 14 | 31001480 | #14 Cover grey (#31001480) |
| 15 | 19001200 | TIMING COVER GASKET (#19001200) USE 887003 |
| 16 | 98622325 | BOLT CHROME (#98622325) |
| 17 | 19007700 | RUBBER (#19007700) |
| 18 | 90402840 | SEAL (#90402840) |
| 19 | 20003510 | Oil Sump (#20003510) |
| 19 | 27003585 | SUMP-DEEP A (#27003585) |
| 20 | 19003602 | PAN GASKET (#19003602) |
| 21 | 31003766 | DRAIN PLUG (#31003766) |
| 22 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 23 | 98620335 | SCREWS (#98620335) |
| 24 | 27001636 | ALTERNATOR COVER (27001636) (#27001636) |
| 25 | 27001136 | FLANGE (#27001136) |
| 26 | 19003400 | COVER (#19003400) |
| 26 | 20003410 | FILTER COVER A (#20003410) |
| 27 | 90706444 | O RING (#90706444) |
| 28 | 27004985 | DIPSTICK (#27004985) USE 883826 |
| 29 | 90706282 | O RING (#90706282) |
| 30 | 12003702 | DRAIN PLUG MAGNETIC (#12003702) |
| 31 | 95100709 | CRUSH WASHER (95100709) (#95100709) |
| 32 | 27152885 | BOLT (#27152885) |
| 33 | 12154200 | OIL LINE CRUSH WASHER (#12154200) |
| 34 | 31999565 | Oil seals - set (#31999565) |
| 35 | 19999021 | #35 Engine set gasket (#19999021) |
| 36 | ||
| 37 | 98620330 | V/COVER BOLT (#98620330) USE 98680330 |
| 38 | 95129180 | WAVE WASHER (#95129180) |
| 39 | 10154200 | GASKET (#10154200) |
| 40 | 95980119 | PLUG (#95980119) |
| 41 | 27991035 | #39 Engine w/o gearbox, blank (#27991035) |
| 41 | 27991036 | Engine w/o gearbox, blank (#27991036) |
| 41 | 27991037 | Engine w/o gearbox, blank (#27991037) |
