1993 1994 Strada 1000 Front Rear Shock Absorber
| Position | Part Number | Description |
|---|---|---|
| 1 | 30490280 | FRT FORK ASSY C (#30490280) |
| 2 | 18513460 | NUT (#18513460) |
| 3 | 18513560 | SHIM (#18513560) |
| 4 | 14494600 | CUP (#14494600) |
| 5 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 6 | 14516700 | SHIM (#14516700) |
| 7 | 14517000 | RING DUST SEAL (#14517000) |
| 8 | 17530260 | STEERING DAMPER (#17530260) |
| 9 | 98052330 | BOLT (#98052330) |
| 10 | 95100141 | WASHER (#95100141) |
| 11 | 91180605 | SPACER (#91180605) |
| 12 | 98054320 | BOLT (#98054320) |
| 13 | 95000206 | WASHER (#95000206) |
| 14 | 92630106 | NUT USE 92630707 (#92630106) |
| 15 | 98230816 | SCREW (#98230816) |
| 16 | 29436650 | FORK BRACE (#29436650) |
| 18 | 90706092 | O RING (#90706092) |
| 19 | 29436450 | BUSHING (#29436450) |
| 20 | 61270300 | WASHER (#61270300) |
| 21 | 95100239 | WASHER (#95100239) |
| 22 | 28550240 | KONI SHOCK SP3, CAL III, MILLE GT, STRADA (#28550240) |
| 23 | 29541850 | PIVOT STUD (#29541850) |
| 24 | 95100535 | WASHER (#95100535) |
| 25 | 29751350 | SUPPORT (#29751350) |
| 26 | 28769533 | BADGE - EAGLE A (#28769533) |
| 27 | 28576047 | SCREW(#28576047) |
| 28 | 29578800 | BRACKET (#29578800) |
| 29 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 30 | 95001206 | WASHER (#95001206) |
