1993 1995 Strada 750 Rear Master Cylinder
| Position | Part Number | Description |
|---|---|---|
| 1 | 19677000 | PEDAL (#19677000) |
| 2 | 14251001 | SHIFT AND BRAKE PEDAL RUBBER (#14251001) |
| 3 | 95129260 | SPRING WASHER (#95129260) |
| 4 | 95004215 | WASHER (#95004215) |
| 5 | 95500227 | COTTER PIN (#95500227) |
| 6 | 19675000 | ROD CONNECTION (#19675000) |
| 7 | 18257551 | BLOCK (#18257551) |
| 8 | 92690073 | NUT (#92690073) |
| 9 | 90271008 | SNAP RING (#90271008) |
| 10 | 95770265 | PIN (#95770265) |
| 11 | 95129110 | WASHER (#95129110) |
| 12 | 95500222 | SPLIT PIN (#95500222) |
| 13 | 31666990 | MASTER CYL ASSY (#31666990) |
| 14 | 19667500 | LEVER (#19667500) |
| 15 | 19667600 | SPRING (#19667600) |
| 16 | 95004206 | WASHER (#95004206) |
| 17 | 98054340 | BOLT A (#98054340) |
| 18 | 95000206 | WASHER (#95000206) |
| 19 | 95021106 | WASHER, WAVE (#95021106) |
| 20 | 92602206 | NUT (#92602206) USE STHN6MM |
| 21 | 65663500 | BRAKE RESERVOIR (#65663500) |
| 22 | 31626860 | #09 Fork (#31626860) |
| 23 | 17661052 | MASTER CYLINDER LID W/ BELLOWS (#17661052) |
| 24 | 00823950050 | TUBE (#00823950050) |
| 25 | 19157800 | CLAMP COMPLETE (#19157800) |
| 26 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 28 | 19659500 | REV KIT (#19659500) |
| 29 | 19659600 | PIN KIT (#19659600) |
| 30 | 17659350 | Rear Master Cylinder Kit (Front for T) (#17659350) |
| 31 | 91180706 | SPACER (#91180706) |
