1994 1996 Sport Carburated 1100 Front Master Cylinder
| Position | Part Number | Description |
|---|---|---|
| 1 | 30660100 | MASTER CYL ASSY B (#30660100) |
| 3 | 30605600 | BRAKE LEVER, (#30605600) |
| 4 | 27604815 | LEVER PIN (#27604815) |
| 5 | 30530526 | BRAKE SWITCH (#30530526) |
| 6 | 30664000 | HALF CLAMP (#30664000) |
| 7 | 19659500 | REV KIT (#19659500) |
| 8 | 30665000 | BRAKE RESERVOIR (#30665000) |
| 9 | 30661100 | RESERVOIR CAP (#30661100) |
| 10 | 30661400 | BRACKET A (#30661400) |
| 11 | 98230612 | ALLEN SCREW (#98230612) |
| 12 | 61013800 | SPRING WASHER (#61013800) |
| 13 | 98230616 | SCREW (#98230616) |
| 14 | 91180607 | SPACER (#91180607) |
| 15 | 91551085 | RUBBER BLOCK USE 9155 1086 (#91551085) |
| 16 | 92630206 | NUT (#92630206) |
| 17 | 00823950050 | TUBE (#00823950050) |
| 18 | 19157800 | CLAMP COMPLETE (#19157800) |
| 19 | 95990028 | SCREW (#95990028) |
| 20 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 21 | 37657105 | BRAKE HOSE (#37657105) |
| 22 | 31656860 | HOSE UNION (#31656860) |
| 23 | 98230625 | ALLEN SCREW A (#98230625) |
| 24 | 37744205 | BRACKET A (#37744205) |
| 25 | 30658800 | BRAKE HOSE RH (#30658800) |
| 26 | 30658801 | BRAKE HOSE LH (#30658801) |
| 27 | 30652302 | CALIPER RH GOLD (#30652302) |
| 28 | 30652202 | CALIPER LH Gold (#30652202) |
| 29 | 98602530 | ALLEN BOLT (#98602530) |
| 30 | 19149800 | WASHER (#19149800) USE AP8152220 |
| 31 | 30654602 | BRAKE PADS SET PR (#30654602) USE FA95 |
| 32 | 30659200 | BLEEDER SCREW KIT (#30659200) |
| 33 | 30659102 | BRAKE PIN KIT (#30659102) |
