1994 1996 Sport Carburated 1100 Ignition Unit
| Position | Part Number | Description |
|---|---|---|
| 1 | 37721405 | DIGIPLEX UNIT (#37721405) |
| 2 | 98052330 | BOLT (#98052330) |
| 3 | 95100141 | WASHER (#95100141) |
| 4 | ||
| 5 | 91180608 | SPACER (#91180608) |
| 6 | 95000206 | WASHER (#95000206) |
| 7 | 92630206 | NUT (#92630206) |
| 8 | 37108105 | VACUUM HOSE A (#37108105) |
| 9 | 61108500 | CLIP (#61108500) |
| 10 | 29721660 | SENSOR IGNITION CAM CRANK (#29721660) |
| 11 | 90706141 | O RING (#90706141) USE 847180 |
| 12 | 29722760 | SENSOR GASKET (#29722760) |
| 13 | 98622210 | SCREW (#98622210) |
| 14 | 95004205 | WASHER (#95004205) |
| 15 | 37407405 | COIL BRACKET (#37407405) |
| 16 | 30716500 | IGNITION COIL (#30716500) |
| 17 | 98620130 | ALLEN BOLT A (#98620130) |
| 18 | 95004204 | WASHER (#95004204) |
| 19 | 92630104 | NUT (#92630104) |
| 20 | 14717600 | SPARK PLUG RUBBER BOOT (#14717600) |
| 21 | ||
| 22 | 30717410 | PLUG CAP NGK (#30717410) USE AP8212219 |
| 23 | 30717061 | SPARK PLUG BPR6ES (#30717061) |
| 24 | ||
| 25 | 30732400 | RELAY HOLDER (#30732400) |
| 26 | 37709905 | MOUNTING PLATE (#37709905) |
| 27 | 30477101 | BRACKET RH (#30477101) USE 304771015 |
| 28 | 30477200 | BRACKET LH (#30477200) |
| 29 | 98622310 | ALLEN BOLT (#98622310) |
| 30 | 61013800 | SPRING WASHER (#61013800) |
| 31 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 32 | 95100121 | WASHER (#95100121) |
| 33 | 91180607 | SPACER (#91180607) |
| 34 | 91551085 | RUBBER BLOCK USE 9155 1086 (#91551085) |
