1994 1996 Sport Carburated 1100 Pierburg Valve System
| Position | Part Number | Description |
|---|---|---|
| 1 | 29116022 | VENT CONTROL VALVE (#29116022) |
| 2 | 28157950 | BREATHER PIPE CLAMP (#28157950) |
| 3 | 29116023 | VENT CONTROL VALVE (#29116023) |
| 4 | 95100628 | WASHER (#95100628) |
| 5 | 92602516 | AXLE NUT FRT (#92602516) |
| 6 | 29119822 | NUT (#29119822) |
| 7 | 29116922 | CONNECTION (#29116922) |
| 8 | 00823941095 | pipe (#00823941095) |
| 9 | 29655722 | EYELET PIPE (#29655722) |
| 10 | 91551120 | GROMMET (#91551120) |
| 11 | 29119122 | RIGID PIPE (#29119122) |
| 12 | 29119022 | RIGID PIPE (#29119022) |
| 13 | 29115822 | CONNECTION (#29115822) |
| 14 | 10154200 | GASKET (#10154200) |
| 15 | 29119222 | BUSH (#29119222) |
| 16 | 37111207 | Joint (#37111207) |
| 17 | 37118807 | VENT HOSE (#37118807) |
| 18 | 00823956050 | Pipe SAE30 R73/16 (#00823956050) |
| 19 | 92630108 | NUT 8MM (#92630108) |
