| Position |
Part Number |
Description |
| 1 |
311002301
|
#01 Fuel tank blank (#311002301) |
| 1 |
31100235
|
#01 Fuel tank, sky blue/white (#31100235) |
| 1 |
31100236
|
#01 Fuel tank white (#31100236) |
| 1 |
31100237
|
#01 Fuel tank, white/Rome blue (#31100237) |
| 1 |
31100238
|
#01 Fuel tank, white/black (#31100238) |
| 1 |
31100239
|
#01 Fuel tank, Carabinieri blue (#31100239) |
| 1 |
89000001
|
#01 Fuel tank, Rome blue (#89000001) |
| 2 |
66103915
|
#02 Fuel filler cap (#66103915) |
| 3 |
66109715
|
#03 Breather pipe (#66109715) |
| 4 |
31105330
|
#04 Fuel cock (#31105330) |
| 5 |
31105830
|
#05 Gasket (#31105830) |
| 6 |
98622316
|
SCREW (#98622316) |
| 7 |
61013800
|
SPRING WASHER (#61013800) |
| 8 |
28157950
|
BREATHER PIPE CLAMP (#28157950) |
| 8 |
29108550
|
HOSE CLAMP (#29108550) |
| 10 |
00823956060
|
T SAEJ 30 R7 6X12 (#00823956060) |
| 11 |
31106630
|
#11 3-way union (#31106630) |
| 12 |
51105401
|
#12 Fuel cock (#51105401) |
| 13 |
51105900
|
#13 Spring (#51105900) |
| 14 |
51105600
|
#14 Cock control (#51105600) |
| 15 |
31101930
|
#15 Plate (#31101930) |
| 15 |
31101931
|
#15 Plate (#31101931) |
| 16 |
98054216
|
SCREW (#98054216) |
| 17 |
95021105
|
LOCK WASHER (#95021105) |
| 18 |
95000205
|
WASHER (#95000205) |
| 19 |
31476235
|
#19 RH side panel, sky blue/white (#31476235) |
| 19 |
314762351
|
#19 RH body panel blank (#314762351) |
| 19 |
31476236
|
#19 RH side panel, white (#31476236) |
| 19 |
31476237
|
#19 RH side panel, white/Rome blue (#31476237) |
| 19 |
31476238
|
#19 RH side panel, white/black (#31476238) |
| 19 |
31476239
|
#19 RH side panel,Carabinieri blue (#31476239) |
| 19 |
89000002
|
#19 RH side panel, Rome blue (#89000002) |
| 20 |
50740600
|
GROMMET (#50740600) |
| 21 |
31476335
|
#21 LH side panel, sky blue/white (#31476335) |
| 21 |
314763351
|
#21 LH body panel blank (#314763351) |
| 21 |
31476336
|
#21 LH side panel, white (#31476336) |
| 21 |
31476337
|
#21 LH side panel, white/Rome blue (#31476337) |
| 21 |
31476338
|
#21 LH side panel, white/black (#31476338) |
| 21 |
31476339
|
#21 LH side panel,Carabinieri blue (#31476339) |
| 21 |
89000003
|
#21 LH side panel, Rome blue (#89000003) |
| 22 |
31460537
|
#22 Single-seater saddle (#31460537) |
| 23 |
28461300
|
FT SEAT HINGE A (#28461300) |
| 24 |
98054316
|
BOLT (#98054316) USE STHB6X16 |
| 25 |
95100139
|
WASHERS (#95100139) |
| 26 |
95021106
|
WASHER, WAVE (#95021106) |
| 27 |
28461345
|
#31 Rear saddle hinge (#28461345) |
| 28 |
27103415
|
#28 Rubber spacer (#27103415) |
| 29 |
92660801
|
CAGE NUT (#92660801) |
| 30 |
27103515
|
#30 Plate (#27103515) |
| 31 |
98622430
|
SCREW (#98622430) |
| 32 |
98230616
|
SCREW (#98230616) |
| 33 |
66478610
|
WASHER (#66478610) |
| 34 |
28103260
|
PIN (#28103260) |
| 35 |
92602208
|
NUT (#92602208) |
| 36 |
51921400
|
#36 On-Off decal (#51921400) |
| 37 |
31917330
|
#37 Moto'zzi dec. (#31917330) |
| 39 |
00823931077
|
GASKET (#00823931077) |
| 40 |
31945435
|
#40 Sticker schema fusibili (#31945435) |
| 41 |
31103835
|
#41 Drift (#31103835) |
| 42 |
98326016
|
SCREW, PAN HEAD (#98326016) |
| 43 |
95100121
|
WASHER (#95100121) |
| 44 |
92630506
|
NUT (#92630506) |
| 45 |
19609600
|
#19 Hose clamp (#19609600) |
