1996 1999 Sport Injected 1100 Dashboard
| Position | Part Number | Description |
|---|---|---|
| 1 | 30766200 | GAUGE PANEL (#30766200) |
| 2 | ||
| 2 | 30758100 | LAMP RED (#30758100) |
| 2 | 30758200 | LAMP BLUE (#30758200) |
| 2 | 30758330 | LAMP ORANGE A (#30758330) |
| 3 | 93450134 | DASH LITES (#93450134) |
| 4 | 30503600 | MOUNT (#30503600) |
| 5 | 92602205 | NUT (#92602205) |
| 6 | 95021105 | LOCK WASHER (#95021105) |
| 7 | 30765100 | GAUGE FOAM A (#30765100) |
| 8 | 14768650 | BULB SOCKET A (#14768650) |
| 9 | 14761570 | SPEEDO KPH B (#14761570) |
| 9 | 28762451 | SPEEDO-140MPH (#28762451) |
| 9 | 30761500 | SPEEDO KPH B (#30761500) |
| 10 | 17768360 | SPEEDO DRIVE GEAR 1185000 (#17768360) |
| 10 | 23768310 | ANGLE DRIVE (#23768310) |
| 11 | 28762860 | TRIP RESET KNOB (#28762860) |
| 12 | 01760400 | SPEEDO CABLE (#01760400) |
| 12 | 37760405001 | REV COUNT.CABLE (#37760405001) |
| 13 | 28762540 | SPEEDO DRIVE ASSY. (#28762540) |
| 14 | 28763340 | DRIVE PINION (#28763340) |
| 15 | ||
| 16 | 01782500 | IGNITION SWITCH (#01782500) |
| 17 | 66468115 | SECURITY BOLT (#66468115) |
| 18 | 01736820 | LOCK SET C (#01736820) |
| 19 | ||
| 20 | 93450120 | BULB ALL GLASS (#93450120) |
| 21 | 90706087 | O RING (#90706087) |
| 22 | 90714101 | WASHER (#90714101) |
| 23 | 30735500 | IGNITION KEY BLANK (#30735500) |
