1996 1999 Sport Injected 1100 Saddles
| Position | Part Number | Description |
|---|---|---|
| 1 | 01460500 | SEAT FRONT (#01460500) |
| 2 | 37463205 | ALLEN BOLT (#37463205) |
| 3 | 95004208 | WASHER (#95004208) |
| 4 | 19461650 | RUBBER PAD (#19461650) |
| 5 | 01464000 | SEAT REAR (#01464000) |
| 6 | 30468700 | LOCK ASSY (#30468700) |
| 7 | 37464405 | SPACER A (#37464405) |
| 8 | 95021019 | LOCK WASHER (#95021019) |
| 9 | 92608618 | NUT A (#92608618) |
| 10 | 37466705 | LOCK LEVER A (#37466705) |
| 11 | 95000206 | WASHER (#95000206) |
| 12 | 98230610 | SCREW (#98230610) |
| 13 | 37465005 | LATCH-SEAT (#37465005) |
| 14 | 37465305 | BUSHING A (#37465305) |
| 15 | 98052430 | BOLT (#98052430) |
| 16 | 95100253 | WASHER (#95100253) |
| 17 | 17667651 | SPRING (#17667651) |
| 18 | 37462505 | SPRING MOUNT A (#37462505) |
| 19 | 98054314 | SCREW (#98054314) |
| 20 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
