1997 1999 V 10 Centauro 1000 Oil Pump
| Position | Part Number | Description |
|---|---|---|
| 1 | 30146401 | OIL PUMP ASSY C (#30146401) |
| 2 | 30148401 | OIL PUMP GEAR (#30148401) |
| 3 | 30147801 | OIL PUMP GEAR A (#30147801) |
| 4 | 91701232 | OIL PUMP KEY (#91701232) |
| 5 | 30147701 | GEAR-PUMP DRIVE A (#30147701) |
| 6 | 98622435 | ALLEN BOLT (#98622435) |
| 7 | 30147000 | WASHER A (#30147000) |
| 8 | 92602308 | NUT (#92602308) |
| 9 | 95990084 | BANJO BOLT (#95990084) |
| 10 | 02153601 | OIL FEED HOSE A (#02153601) |
| 11 | 95990057 | Oil pipe screw (#95990057) |
| 12 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 13 | 17768750 | OIL SENDER (#17768750) |
| 14 | 12006400 | ALUM CRUSH WASHER (#12006400) |
| 15 | 30018346 | COVER GREY (#30018346) |
| 16 | 90706313 | O RING (#90706313) |
| 17 | 98250820 | SCREW (#98250820) |
| 18 | 00823952080 | FUEL HOSE V11 SPORT (#00823952080) |
| 19 | 93305017 | HOSE CLAMP (#93305017) |
| 20 | 28007250 | BREATHER PIPE (#28007250) |
| 21 | 12007600 | OIL RETURN GASKET (#12007600) |
| 22 | 98054320 | BOLT (#98054320) |
| 23 | 95120065 | WASHER (#95120065) |
| 24 | 93305018 | CLAMP A (#93305018) |
| 25 | 30157400 | BREATHER HOSE (#30157400) |
| 26 | 01154600 | OIL RET HOSE (#01154600) |
| 27 | 01162800 | HOSE GUIDE A (#01162800) |
| 28 | 01006600 | BANJO BOLT A (#01006600) |
| 29 | 10154200 | GASKET (#10154200) |
| 30 | 91181613 | SPACER A (#91181613) |
