1997 1999 V 10 Centauro 1000 Saddle Central Bod
| Position | Part Number | Description |
|---|---|---|
| 1 | 02460500 | SEAT CENTAURO (#02460500) |
| 1 | 02460510 | SEAT CENTAURO SPORT (#02460510) |
| 1 | 02460515 | DUAL SEAT (#02460515) |
| 2 | 02462300 | SEAT STRAP (#02462300) |
| 3 | 98054314 | SCREW (#98054314) |
| 4 | 95100121 | WASHER (#95100121) |
| 5 | 02466301 | COWL SEAT (#02466301) |
| 5 | 02466302 | (#02466302) |
| 5 | 02466303 | YELLOW SEAT CVR (#02466303) |
| 5 | 02466330 | RED SEAT CVR (#02466330) |
| 5 | 02466331 | GREEN SEAT CVR (#02466331) |
| 5 | 02466400 | Cover pillion rider seat blank (#02466400) |
| 6 | 02517700 | EMBLEM FOR ALTERNATOR COVER 1100 EV (#02517700) |
| 7 | 02999501 | MOUNT KIT (#02999501) |
| 8 | 98230615 | ALLEN SCREW A (#98230615) |
| 9 | 95004206 | WASHER (#95004206) |
| 10 | 02461500 | TAIL COVER (#02461500) |
| 11 | 92630106 | NUT USE 92630707 (#92630106) |
| 12 | 95100120 | WASHER (#95100120) use 95105320 |
| 13 | 02573100 | SEAT COWL BARE B (#02573100) |
| 13 | 02573101 | SEAT COWL RED NLA D (#02573101) |
| 13 | 02573102 | (#02573102) |
| 13 | 02573103 | REAR TAIL BODY WORK (#02573103) |
| 13 | 02573130 | SEAT COWL RED D (#02573130) |
| 13 | 02573131 | SEAT COWL GRN D (#02573131) |
| 14 | 02922000 | DECAL V10 SILVER (#02922000) |
| 14 | 02922030 | DECAL V10 RH A (#02922030) |
| 14 | 02922130 | DECAL V10 LH A (#02922130) |
| 15 | 98230618 | ALLEN BOLT A (#98230618) |
| 16 | 29577860 | PLASTIC WASHER (#29577860) |
| 17 | 02976210 | RACK KIT D (#02976210) |
| 18 | 02466511 | LUGGAGE RACK X (#02466511) |
| 19 | 02467410 | PLATE RH FRT A (#02467410) |
| 20 | 02467411 | PLATE LH FRT A (#02467411) |
| 21 | 02467610 | PLATE REAR A (#02467610) |
| 22 | 02469710 | PAD RH FRONT(#02469710) |
| 23 | 02469711 | PAD LH FRONT (#02469711) |
| 24 | 02469810 | PAD REAR (#02469810) |
| 25 | 98250614 | ALLEN SCREW A (#98250614) |
| 26 | 98250630 | ALLEN BOLT (#98250630) |
| 27 | 02467310 | SPACER A (#02467310) |
| 28 | 02940430 | DECAL RH COVER A (#02940430) |
| 29 | 02940530 | DECAL LH COVER A (#02940530) |
| 31 | 02922330 | DECAL RH REAR A (#02922330) |
| 32 | 02922430 | DECAL LH REAR A (#02922430) |
