1997 1999 V 10 Centauro 1000 Top Box Support
| Position | Part Number | Description |
|---|---|---|
| 1 | 02487510 | TOPCASEKIT 40L S (#02487510) |
| 2 | 31487665 | REAR TRUNK (#31487665) |
| 3 | 03482001 | 50 MM (1 7/8) TRUNK BADGE EACH (#03482001) |
| 4 | 02487710 | BRACKET (#02487710) |
| 5 | 02487910 | Spacer (#02487910) |
| 6 | 98230650 | SCREW (#98230650) |
| 7 | 95100141 | WASHER (#95100141) |
| 8 | 92630106 | NUT USE 92630707 (#92630106) |
| 9 | 03484001 | SADDLEBAG LOCK (#03484001) |
| 10 | 03484000 | BAG CLAMP KIT (#03484000) |
| 11 | 02944310 | PLATE (#02944310) |
