1997 2000 California EV (v11 EV Usa) 1100 Cdi Unit Assy II
| Position | Part Number | Description |
|---|---|---|
| 1 | 03725830 | HARNESS-FI D (#03725830) |
| 2 | 03729531 | COMPUTER OR CDI UNIT ECU/CALIFORNIA (#03729531) |
| 3 | ||
| 4 | 28742560 | FUSE 15A (#28742560) use 290860 |
| 5 | 03729230 | MOUNTING PLATE (#03729230) |
| 6 | 93221330 | RUBBER MOUNT (#93221330) |
| 7 | 98054110 | BOLT (#98054110) |
| 8 | 95000204 | WASHER (#95000204) |
| 9 | 98230612 | ALLEN SCREW (#98230612) |
| 10 | 61013800 | SPRING WASHER (#61013800) |
| 11 | 92660601 | CAGE NUT (#92660601) |
| 12 | ||
| 13 | 14717600 | SPARK PLUG RUBBER BOOT (#14717600) |
| 14 | 30717410 | PLUG CAP NGK (#30717410) USE AP8212219 |
| 15 | 30717061 | SPARK PLUG BPR6ES (#30717061) |
| 16 | 01721600 | TIMING SENSOR (#01721600) |
| 17 | 98622210 | SCREW (#98622210) |
| 18 | 30729331 | AIR/OIL TEMP SENSOR (30729331) USE 30729330 (#30729331) |
| 19 | 90706141 | O RING (#90706141) USE 847180 |
| 20 | 29722760 | SENSOR GASKET (#29722760) |
| 21 | 30716500 | IGNITION COIL (#30716500) |
| 22 | 28716748 | COIL BRACKET (#28716748) |
| 23 | 98622310 | ALLEN BOLT (#98622310) |
| 25 | 98622125 | ALLEN BOLT A (#98622125) |
| 26 | 92602206 | NUT (#92602206) USE STHN6MM |
| 27 | 95021104 | WASHER (#95021104) |
| 28 | 93222020 | RUBBER MOUNT (#93222020) USE 93222023 |
| 29 | 30728230 | BRACKET A (#30728230) |
| 30 | 98610110 | ALLEN BOLT (#98610110) |
| 31 | 03727800 | LED - RED (#03727800) |
| 32 | 30732900 | LED BRACKET (#30732900) |
| 33 | 92601003 | NUT A (#92601003) |
| 34 | 29729461 | OIL TEMP SENSOR (#29729461) |
| 35 | 03163330 | SENSOR HOLDER A (#03163330) |
| 37 | 92602204 | NUT (#92602204) |
| 38 | 03738500 | HARNESS-F/PUMP A (#03738500) |
| 39 | 30759600 | CABLE BOOT A (#30759600) |
| 41 | 95004205 | WASHER (#95004205) |
| 42 | 30732400 | RELAY HOLDER (#30732400) |
| 43 | 30732200 | FUSE HOLDER (#30732200) |
