1997 2000 California EV (v11 EV Usa) 1100 Foot Rests
| Position | Part Number | Description |
|---|---|---|
| 1 | 03420300 | FRAME LWR RH C (#03420300) |
| 2 | 03422100 | FRAME LWR LH C (#03422100) |
| 3 | 03446900 | RH CHROME COVER 1100 EV FRAME (#03446900) |
| 4 | 03447400 | LH LOWER CHROME FRAME COVER (#03447400) |
| 5 | 98230621 | ALLEN BOLT(#98230621) |
| 6 | 95004208 | WASHER (#95004208) |
| 7 | 93231606 | RUBBER BUSHING (#93231606) |
| 8 | 30447060 | FOOTPAD USE 03447070 (#30447060) |
| 9 | 29443501 | FOOTBOARD W/O PAD (#29443501) |
| 10 | 98052430 | BOLT (#98052430) |
| 11 | 92630108 | NUT 8MM (#92630108) |
| 12 | 14429500 | BOLT (ROD) (#14429500) |
| 13 | 95000213 | WASHER (#95000213) |
| 14 | 92602312 | NUT (#92602312) |
| 15 | 29443550 | MOUNT (#29443550) |
| 16 | 23440710 | RF FOOTPEG A (#23440710) |
| 17 | 29446050 | L H PLATE (#29446050) |
| 18 | 23441810 | LF FOOTPEG A (#23441810) |
| 19 | 23443210 | FOOTREST RUBBER (#23443210) |
| 20 | 23441210 | FOOTREST PLATE (#23441210) |
| 21 | 98054314 | SCREW (#98054314) |
| 22 | 61013800 | SPRING WASHER (#61013800) |
| 23 | 91180602 | SPACER (#91180602) |
| 24 | 29442250 | BOLT (#29442250) |
| 25 | 61270300 | WASHER (#61270300) |
| 26 | 92630508 | NUT (#92630508) |
| 27 | 98623635 | SCREW USE 9881 3635 (#98623635) |
| 28 | 98621650 | SCREW (#98621650) |
| 29 | 17444250 | SPACER (#17444250) |
| 30 | 95100414 | WASHER (#95100414) |
| 31 | 95021112 | WASHER (#95021112) |
| 32 | 92602512 | NUT (#92602512) |
| 34 | 98623640 | SCREW (#98623640) |
| 35 | 93180245 | RUBBER PLUG (#93180245) |
| 36 | 95000206 | WASHER (#95000206) |
| 37 | 30425260 | CROSS BRACE A (#30425260) |
| 38 | 98054522 | BOLT (#98054522) |
| 39 | 95021110 | WASHER (#95021110) |
| 40 | 29447150 | RUBBER PAD A (#29447150) |
| 41 | 00823931055 | GASKET (#00823931055) |
| 42 | 98230615 | ALLEN SCREW A (#98230615) |
